Rain Cloud

General Information

Collection Name

Classic

Manufacturer SKU

519SA-2x2

Price Range

£££

Product Name

Rain Cloud

Material & Finish

Construction

Pre-Cast / Moulded

Content

100% Acrylic Resin

Format

Panel / Sheet

Availability & Procurement

Availability

Unavailable

Technical Specifications

Dimensional Stability

ASTM D-696 Thermal Expansion - 1.3 in 10-6 in/in/°F

Impact Resistance

NEMA LD3-3 (1/2lb ball) - >125 in

Length

3660

Overall Thickness

12

Total Weight

60 kgs (132 lbs)

Applications & Usage

Application Filter

Bath|Countertop|Kitchen|Wall|Wall/Backsplash|Wall/Wet Wall & Shower Wall

Installation

Refer to Fabrication Manual PDF attachment for details.

Performance Metrics

Antimicrobial Testing

ASTM G21 Fungi Resistance - No Growth after 28 days; ASTM G-22 Bacteria & Germ Resistance - No Change

Color Stability From Heat

NEMA LD3-3-10 - No Change

Flammability

UBC8-1(NFPA No.255) - Class 1/A; ASTM E 84 Flame Spread - Class 1/A (FSI @ 10); ASTM E 84 Smoke Density - Class 1/A (SDI @ 5)

Flexural Strength

ASTM D-790 - 9,000 psi

Hardness

Barcol / Rockwell - 60 / 90

Maintenance

Refer to Care and Maintenance PDF attachment for details

Stain Resistance

Passes ASNI 124.3 & 124.6 -2007

Tensile Strength

ASTM D-638 - 6,000 psi

Water Absorption

ASTM D-570 - 0.04% (24 hours)

Human Health
