This material is designed for use with Autex Acoustics products only.
Warranty
10 years
Material & Finish
Construction
Non-Woven, Felted
Content
100% Polyester Fibre (PET)
Format
Panel / Sheet
Availability & Procurement
Availability
Typically Stocked
Country Of Origin
United States
Custom Capabilities
Cube panels are customizable with Print, Mold & Press, Precision Cut, Groove, and Peel ‘n’ Stick, and require no edging or capping
Lead Time
3-6 weeks
Technical Specifications
Impact Resistance
ISO 7892:1988. May show surface damage from impacts. Not recommended for contact areas.
Overall Thickness
6
Size
Panel: 4 ft x 8 ft; 4 ft x 8 ft 10 in; Tolerance (+0.2 in) x (+0.4 in); Raft: Fin length 8 ft, Tolerance (+/-0.02 in)
Applications & Usage
Application Filter
Ceiling|Wall
Recommended Adhesive
Refer to product-specific install instructions
Suitable Substrates
Non-contact areas recommended. Follow base product substrate requirements.
Performance Metrics
Acoustics
Panel: NRC 0.30 (3/8"); NRC 0.70 (1"); NRC 0.80 (1" with air gap). Ceiling Tile: NRC 0.85 (1/2" with 1/2" air gap)
Antimicrobial Note
ASTM G21-15 Growth Rating 0 — no mold or mildew growth. WARNING: Isopropanol, alcohol, and sanitisers are NOT recommended for Acoustic Timber or Surface Finishes — damages UV-cured ink surface.
Crocking
ISO 105-X12:2016 - Dry rating: 4-5 (out of 5); Wet rating: 4-5 (out of 5)
Flammability
Panel: ASTM E84 Class A FS:24 SD:250 (3/8"); Class A FS:0 SD:65 (1"); CAN/ULC-S102 FS:15 SD:65 (3/8"); Ceiling Tile: ASTM E84 Class A FS:0 SD:45
Light Blocking
Complete
Maintenance
Light dusting or vacuuming with soft brush only. Mild detergent by blotting with microfiber cloth; do NOT rub. WARNING: No isopropanol, alcohol, acetone, solvents, or sanitisers — damages UV ink surface. Consult specialist cleaner.
Sustainability
Human Health
Human Health Impact
CDPH Standard Method v1.2-2017, Declare Product Label, Declare Product Label - LBC Red List Free, Low Emitting/Low VOC
Climate Health
Climate Impact
Environmental Product Declaration (EPD), ISO 14001 Environmental Management System (EMS), SCS Carbon Neutral Certification
