Belden nomenclature differs from industry standards on certain or several brick sizes. Namely we use the term Jumbo instead of Engineer and the term Economo where the industry uses Closure
Material & Finish
Construction
Extruded
Content
Fireclay
Format
Modular
Availability & Procurement
Availability
Unavailable
Country Of Origin
United States
Technical Specifications
Size
3.625in W x 2.25in H x 7.625in L (Modular), 3.625in W x 3.625in H x 7.625in L (Economo Modular), 3.625in W x 2.25in H x 11.625in L (Norman), 3.625in W x 3.625in H x 11.625in L (Utility), 3.625in W x 7.625in H x 11.625in L (Double Utility), 3.625in W x 7.625in H x 7.625in L (Quad), 3.625in W x 3.625in H x 15.625in L (Monarch), 5.625in W x 3.625in H x 15.625in L (Monarch 5.625in Thru Wall), 7.625in W x 3.625in H x 15.625in L (Monarch 7.625in Thru Wall), 3.625in W x 7.625in H x 15.625in L (Double Monarch), 3.625in W x 2.25in H x 15.625in L (Ambassador)
Applications & Usage
Application Filter
Facade|Wall
Performance Metrics
Compression
19,508 psi
Light Blocking
Complete
Sustainability
Human Health
Human Health Impact
Low Emitting/Low VOC
Climate Health
Climate Impact
ISO 14001 Environmental Management System (EMS), CARB Compliant
