Sculptform Click-on Battens Aluminium - Block | Product
Click-on Battens Aluminium - Block
Sculptform
Walls
Overnight
Commercial & Residential
$$$
Core Specs
General Information
Manufacturer SKU
COBBWFAO
Price Range
$$$
Product Name
Click-on Battens Aluminium - Block
Material & Finish
Content
Aluminum
Availability & Procurement
Availability
Made to Order / Special Order
Custom Capabilities
Custom Length up to 6 m
Manufacturing Location
Golden Square, Victoria, Australia
Technical Specifications
Length
6.2
Product Features
Customizable
Size
40 mm x 20 mm, 120 mm x 20 mm, 30 mm x 30 mm, 25 mm x 50 mm, 50 mm x 50 mm, 30 mm x 60 mm, 40 mm x 100 mm, 25 mm x 100 mm
Applications & Usage
Application Filter
Ceiling|Facade|Wall
Installation
Mounting Options: Standard Track (45x25 mm), Slim Track (25x25 mm), Curving Track (45x17 mm), Trackless, Split Track (35x25 mm), Suspended Ceiling Track (45x32 mm)
Performance Metrics
Acoustics
NRC 0.4 (when using 90mm air cavity). To see the acoustic performance of a specific design, use our Price & Spec tool
Light Blocking
Complete
Sustainability
Human Health
Human Health Impact
Declare Product Label - LBC Red List Approved
Climate Health
Climate Impact
100% Recyclable
Circular Economy
Circular Economy
100% Recyclable, Declare Product Label - LBC Red List Approved
Certifications & Disclosures
Disclosure Level
100 ppm
Ingredient Disclosure
Declare Product Label
