American Biltrite Electrotile | Product
Order sample WHITE/TAUPE
Sample size: 3 in x 3 in x 0.1 in
Almond Shell
Sky Blue
Grey
Mineral Grey
Luxe Grey
Taupe
Mission White
White
White/black
White/blue
White/grey
White/taupe
Core Specs General Information
Collection Name ELECTROTILE®
Color Name WHITE/TAUPE
Color Number 140
Manufacturer SKU ESD-43
Price Range $$$
Product Name Electrotile
Warranty 20 Year Limited Wear & Lifetime Conductivity Warranty Material & Finish
Construction Homogeneous
Content Phthalate-Free Vinyl
Format Modular Availability & Procurement
Availability Typically Stocked, Stocked in North America
Country Of Origin Canada
Lead Time 4-6 weeks standard but may vary depending on quantities and project. Contact your sales rep for details
Order Increments 12in Tile - 45 sqft (4.181 sqm) Coverage, 24in Tile - 40 sqft (3.716 sqm) Coverage, 36in Tile - 9 sqft (0.836 sqm) Coverage Technical Specifications
Overall Thickness 3.17
Size 12in x 12in (305mm x 305mm), 24in x 24in (610mm x 610mm), 36in x 36in (915mm x 915mm) Applications & Usage
Application Filter Flooring|Flooring/Electrostatic Dissipative Flooring|Flooring/Flooring for Radiant Heat Systems
Installation Adhesive but can be flash coved or heat welded for increased hygiene. Grounding required using 3/8in wide copper foil tape. Refer to Installation attachment for details Performance Metrics
Abrasion Wear Resistance Passes ASTM D3389 - Abrasion Resistance (H-18,500 g @ 1,000 cycles)
Classification ASTM F1700 - Class I, Type A, Monolithic
Color Stability From Heat ASTM F1514 - ΔE ≤ 8.0
Compression ASTM F970 Static Load (Modified at 2,500 psi) = 0.005in; ASTM F1914 Residual Indentation < 8%
Electrical Resistance
ASTM F150 Dissipative Tile - Between 1 x 106; Federal Standard - Method 101 B, Method 4048 Complies, (Static Decay 5,000 Volts to 0 Volt) Ohms and 1 x 109 Ohms (1 MOhms and 1,000 MOhms)
Electrostatic Propensity AATCC 134 - Complies
Flammability ASTM E648 Critical Radiant Flux (W/cm2) = 0.45; ASTM E662 Smoke Density = 450
Flexural Strength Passes ASTM F137
Lightfastness ASTM F1515 - ?E = 8.0
Maintenance Refer to Maintenance attachment for details
Slip Resistance ASTM D2047 Static Coefficient of Friction (leather) = 0.5 Sustainability Human Health
Human Health Impact CDPH Standard Method v1.2-2017, Low Emitting/Low VOC, Phthalates free, REACH Compliant, SCS Global FloorScore Certified
VOC Emissions Testing Methodology CDPH / CHPS 01350 Compliant Climate Health
Climate Impact CARB Compliant, Environmental Product Declaration (EPD), ISO 14001 Environmental Management System (EMS) Ecosystem Health
Ecosystem Health ISO 14001 Environmental Management System (EMS) Social Health & Equity
Organizational Commitments ISO 14001 Circular Economy
Circular Economy Environmental Product Declaration (EPD) Certifications & Disclosures
LEED May contribute to LEED credits.
VOC Emissions Testing Certificate FloorScore Certified
