General Information
- Collection Name
- Signature Collection
- Color Name
- Kingswood Signature Micro Bevel
- Manufacturer SKU
- SA-MR-KING-SM-CUT
- Price Range
- $$$$
- Product Name
- Kingswood Signature Micro Bevel
- Series Name
- Modin
- Warranty
- Lifetime Residential / 20-year Commercial
Material & Finish
- Backing
- 1.5 mm IXPE Foam Underlayment
- Construction
- Heterogeneous SPC Engineered Vinyl Plank
- Content
- Virgin PVC, Limestone
- Finish
- Aluminum Oxide Coating
- Format
- Modular, Plank
Technical Specifications
- Edge End
- Enhanced Painted Bevels - Micro Bevels
- Impact Resistance
- Passes ASTM F1265-03a Requirement - Steel cylinder with diameter of 1in, weight 159g, break or cracks not observed
- Length
- 72
- Overall Thickness
- 7.2
- Size
- 9 in x 72 in
- Wear Layer Thickness
- 40 mil (1 mm)
Performance Metrics
- Abrasion Wear Resistance
- ASTM F510/F510M-14 - 3.7 (mm3 / 100r); Passes NALFA LF 01-2011 Castor Chair Resistance Requirement - After 25000 cycles, no visible damage
- Durability
- Heavy Duty
- Flammability
- ASTM C518-17 Thermal Conductivity and Thermal Resistance - Conductivity 0.119 (W/m·K) Resistance 0.060 (m2·K)/W
- Lightfastness
- Passes ASTM F1515-15 Requirement - Delta E no greater than 8.0 after 300th exposure
- Slip Resistance
- ASTM D2047-11 Static Coefficient of Friction (Standard Leather) - Dry 0.51, Wet 0.62
