Technical Specifications
- Dimensional Stability
- Passes ASTM F2199 at -0.003in/lin ft
- Edge End
- Micro Beveled Edge
- Impact Resistance
- Passes NALFA 3.6 Small Ball Impact - Class 4; Passes NALFA 3.5 Large Ball Impact - Class 4
- Overall Thickness
- 6.5
- Size
- 9in x 56in (225mm x 1420mm)
- Wear Layer Thickness
- 20 mil
Performance Metrics
- Abrasion Wear Resistance
- Passes ASTM D4060 - 36,000 cycles
- Acoustics
- ASTM E2179-09 - Delta IIC = 22 dB; ASTM E492-09 IIC = 68 dB (6in Concrete Slab w/ Drop Ceiling), IIC = 72 dB (6in Slab w/ Drop Ceiling + QuietChoice)
- Classification
- ASTM F3261 - Resilient Flooring with Rigid Polymeric Core
- Color Stability From Heat
- Passes ASTM F1514
- Compression
- Passes ASTM F970 Static Load - 800 psi at 0.005in
- Durability
- Heavy Duty
