Technical Specifications
- Product Features
- Customizable
- Size
- Panel Size: Lay-In: Width up to 2 ft, Length up to 6 ft, Available in 30 in x 30 in; Semi-Concealed: Width up to 2 ft, Length up to 4 ft; Concealed Access: Width up to 4 ft, Length up to 8 ft, Wall: Width up to 4 ft, Length up to 8 ft
- Total Weight
- Varies 2.0 - 4.0 lbs/ft2
Performance Metrics
- Acoustics
- P3 - NRC 0.70/ CAC - 37, P4 - NRC 0.75/ CAC - 37, S5 - NRC 0.80/ CAC - 37, S6 - NRC 0.70/ CAC - 37, C7 - NRC 0.80/ CAC - 37, C8 - NRC 0.90/ CAC - 37, C9 - NRC 0.70/ CAC - 37
- Light Blocking
- Complete
- Maintenance
- Refer to Maintenance PDF for details
