REHAU RAUVISIO Brilliant | Product

Core Specs

General Information

Collection Name: Decorative Design Collection
Color Name: Meringa
Color Number: 5026B
Manufacturer SKU: 380003-002
Price Range: $$$
Product Name: RAUVISIO Brilliant
Warranty: 10 years for certain applications
Manufacturer Notes: Suitable for contact with foodstuffs. Can be drawn on using standard whiteboard markers

Material & Finish

Construction: Offered as individual matching components (laminate, pressed board and edgeband) or as finished, cut-to-size components
Content: A multi-layer coextruded polymer produced from a styrene copolymer base layer and an acrylate top layer. By request, can come assembled as a pressed board consisting of the acrylic laminate, MDF board, and color-coordinated balancing sheet
Finish: High-gloss. No hard coat finish. Can be finished using the REHAU sealing kit
Format: Panel / Sheet

Availability & Procurement

Availability: Typically Stocked, Stocked in North America
Country Of Origin: Italy
Custom Capabilities: With the REHAU surface configurator, configure and order made-to-measure, invisible joint panels quickly and easily with no minimum order
Lead Time: 1 week

Technical Specifications

Edge End: Two offerings include RAUKANTEX edgebanding and REHAU LaserEdge
Overall Thickness: 19
Product Features: Customizable
Size: 2800mm x 1300mm

Applications & Usage

Application Filter: Bath|Kitchen|Furniture|Wall|Wall/Backsplash
Installation: Can be bent and cut into virtually any shape. Cut-to-size and mechanical processing can be completed using standard, sharpened woodworking tools
Recommended Adhesive: RAUVISIO Flat-Lam PUR or a single component PU hotmelt is recommended.
Suitable Substrates: Wooden substrates, lightweight boards or composite material substrates are suitable. MDF is recommended for a high-quality surface finish. The specially developed balancing sheet is perfectly color-matched to the acrylic sheet. The material thickness of the balancing sheet ensures minimal warpage of the board assembly.

Performance Metrics

Abrasion Wear Resistance: DIN 68861 Scratch-resistance Tested. Class 4D
Flammability: Categorized to DIN 4102-B2 as normal flame resistance
Light Blocking: Complete
Lightfastness: DIN EN ISO 4892-2, process B Tested. Level 7. DIN EN ISO 105 A02 Tested. Less than or equal to Level 4
Maintenance: Clean with a damp microfiber cloth and with a mild soap if needed. Do not dry-wipe the acrylic finish. Avoid abrasive cleaners, solvent-based cleaners and harsh chemicals. Do not use paper towels, brushes, or scouring pads

Sustainability

Climate Health

Emissions: In case of fire, no toxic substances such as heavy metals or halogens are released
