Available in 2 ft x 2 ft for one-to-one access floor installation
Technical Specifications
Carpet Pile Height
0.182 in Tufted Pile Height; 0.144 in Pile Thickness
Overall Thickness
0.28 in
Pile Face Weight
26 oz./sq. yd. (882 g/sm)
Yarn Tuft Details
1/12 in gauge, 10.0 in tufted stitches per inch
Applications & Usage
Installation
Use only StaticWorx-approved conductive adhesives. GroundTack pressure sensitive. TacTiles glue-free self-stick connectors for adhesive-free installation over raised access floors. Refer to Installation Instructions PDF for more details
Installation Direction
Monolithic
Performance Metrics
Flammability
ASTM E 648 Radiant Panel Class 1; ASTM E 662 Smoke Density = 450 ; Passes Methenamine Pill Test (DOC-FF1-70)
Lightfastness
AATCC 16 – E - = 4.0 @ 60 AFUs
Surface Pile Density
6,500 oz/yd³
Sustainability
Human Health
Human Health Impact
CDPH Standard Method v1.2-2017, CRI Green Label Plus Indoor Air Quality, Green Label Plus, Low Emitting/Low VOC
VOC Emissions Testing Methodology
CDPH / CHPS 01350 Compliant
Climate Health
Emissions
Private Office Range of Total VOCs: 0.5mg/m³ or less; School Classroom Range of Total VOCs: 0.5mg/m³ or less
