<ul> <li>LED module with single light emitting source, thermally managed to provide optimal performance</li> <li>Specifiable in 2700K–4000K in CRI >80 or CRI >90, color accuracy within 3 SDCM; Also available in dim-to-warm</li> <li>PoE or PoE+ compatible (depending on required output): Integrates with Power over Ethernet lighting systems through standard, low voltage wires</li> <li>Beam spreads from 30 degree narrow flood to 78 degree wide flood available, achieved with optics that are easily changed in the field</li> <li>Reported: L90 > 55,000 hrs; Calculated: L70 > 180,000 hrs; L80 > 120,000 hrs; EPA TM21 calculator derived</li> <li>Canopy mounts to 4in octagonal junction box or appropriate alternative</li> </ul>
Product Name
Acoustic Trellis Wave
Warranty
5 years
Material & Finish
Content
PET Felt
Availability & Procurement
Availability
Made to Order / Special Order
Country Of Origin
United States
Custom Capabilities
Custom sizing available upon request
Lead Time
6 weeks
Technical Specifications
Product Features
Customizable
Size
48in on center square cell. Height is 14in. Refer to PDF attached for details
Applications & Usage
Application Filter
Ceiling|Lighting
Installation
12in-96in fully adjustable stainless steel aircraft cable suspension. Contact studio for additional lengths up to 20ft. Refer to Installation Instructions PDF for more details
Performance Metrics
Acoustics
NRC Rating of 1.00; ASTM C423; ISO 354
Light Blocking
Complete
Maintenance
Use vacuum or soft brush to clean Shade. Do not use strong solvents, highly alkaline or abrasive cleaning agents
