<ul><li>Light Source - 1 x G9-base bulb (40 W max)</li><li>Light Concept - AJ Discus was designed by Arne Jacobsen in 1956 for R¸dovre Town Hall. Two sizes were produced for this project350 and ˜450. They were used indoors on stairways and outdoors as wall lamps. A ˜220 version was later designed for St. Catherines College in England. Arne Jacobsen preferred the largest model when specifying his own projects. Today, AJ Discus is used worldwide and in a variety of architectural contexts. </li><li>Efficacy - 8, Delivered from 37.1 lm/W - 80.7 lm/W</li><li>Certifications - cULus</li><li>Wet Location (Incandescent variants)</li><li>Damp location (LED variants)</li><li>Protection class IP20</li><li>Controllability: 0-10V Dimming</li><li>Phase Dimming</li><li>Color Rendering: Ra=90. For the E-socket product variants, bulbs are not included. LED light source is part of the product</li><li>UGR Transversal / Axial - 14.7/14.7Voltage - 120V, 60Hz</li><li>Specification Notes - 8.7 in size available only in either 10W LED/3000K or 40W T4/G9 lamping</li></ul>
Product Name
AJ Eklipta Ceiling Lamp
Material & Finish
Content
Ceiling/Wall Box: Spun Aluminum, Diffuser: Hand Blown White Opal Glass
Finish
White, Powder Coated, White Opal Glass
Lamping
LED
Availability & Procurement
Availability
Made to Order / Special Order
Lead Time
6 Weeks
Technical Specifications
Lighting Type
Semi-Flush Mount
Size
8.7 in W x 4.1 in H x 8.7 in L
Total Weight
1.3 lbs
Applications & Usage
Application Filter
Ceiling|Lighting
Installation
Mounting-Surface: Mounted directly to finished surface over a recessed 4 in octagonal junction box (13.7 in/17.7 in) or 3 in octagonal junction box (8.7 in); For mounting instructions; see download section on the product detail page
