ASTM D5420 Gardner Impact - Up to 198in lbs in force
Overall Thickness
2.5
Size
10 ft 4 in x 9 ft 10 in (3.15m x 3.0m)
Total Weight
28.22 lbs (12.8 kg)
Applications & Usage
Application Filter
Wall
Installation
Must be installed by a professional installer that has attended the Altro Whiterock Installation Clinic. Refer to Installation Guide attachment for details
Performance Metrics
Antimicrobial Note
Resists mold and fungi growth.
Compression
DIN 53454 Compressive Strength - 70 N/sq mm
Durability
Heavy Duty
Electrical Resistance
DIN IEC 60167 Surface Resistance - 2.00E +14, DIN IEC 243 Dielectric Strength - 16.8 kV/mm, DIN 53483 Dielectric Loss Index - 0.02, DIN IEC 60 093 Volume Resistance - 6.90E+13, DIN 53583 Dielectric Constant - 3.2
Flammability
ASTM E84 - Class A; CAN/ULC - S102.2 Tested
Flexural Strength
ISO 178 - 79.8 Mpa
Lightfastness
Tested in accordinance with ASTM G154 standards
Maintenance
AltroClean 44 is the recommended cleaner. Refer to Maintenance attachment for details
Tensile Strength
ISO 527 - 48 Mpa
Sustainability
Human Health
Human Health Impact
CDPH Standard Method v1.2-2017, Low Emitting/Low VOC
