Limited 25 Year Commercial Warranty; Limited 25 Year Quantum Guard Elite® Wear Warranty
Material & Finish
Construction
Luxury Vinyl Tile
Content
Non-Ortho Phthalate Vinyl
Finish
Quantum Guard Elite®; QuickStix
Format
Modular, Plank
Availability & Procurement
Availability
Unavailable
City Of Origin
Madison
Country Of Origin
United States
Lead Time
Please contact your sales rep for details
Manufacturing Location
Madison, GA
Technical Specifications
Dimensional Stability
ASTM F2199 - Max 0.020 in/lin ft
Edge End
Micro-Bevel or Unbeveled Edges
Overall Thickness
2.5
Size
12 in x 12 in, 12 in x 18 in, 12 in x 24 in, 18 in x 18 in, 18 in x 24 in, 18 in x 36 in, 18 in x 48 in, 4.5 in x 36 in, 6 in x 36 in, 9 in x 36 in. Sizes are style dependent - refer to size chart for specific product sizes
Wear Layer Thickness
40 mil (1 mm)
Applications & Usage
Application Filter
Flooring
Installation
Adhesive - use V-95, MoistureLoc or XpressStep under hospital beds/heavy rolling loads; in abusive conditions (dragging force, direct sunlight, topical moisture) use only V-95 or MoistureLoc. QuickStix pre-applied adhesive available
Recommended Adhesive
V-95, MoistureLoc or XpressStep
Performance Metrics
Classification
ASTM F1700 Class III, Type B
Color Stability From Heat
Passes ASTM F1514
Compression
ASTM F970 Static Load = 0.005in; ASTM F970 Static Load (Modified) - 2,000 PSI, Residual Indent less than or equal to 0.005in; Passes ASTM F1914
Flammability
Passes ASTM E648 Flooring Radiant Panel - Class 1, Greater than or equal to 0.45 watts/cm2; Passes ASTM E662 Smoke Density - Less than or equal to 450
Flexural Strength
ASTM F137 - 1in Mandrel - No Crack/Break
Light Blocking
Unknown
Lightfastness
Passes ASTM F1515
Slip Resistance
Passes ASTM C1028 - ≥ 0.5 Leather; 0.6 Rubber
Sustainability
Human Health
Human Health Impact
CDPH Standard Method v1.2-2017, Low Emitting/Low VOC, SCS Global FloorScore Certified, Health Product Declaration (HPD)
VOC Emissions Testing Methodology
CDPH / CHPS 01350 Compliant
Climate Health
Climate Impact
UN Global Compact, Environmental Product Declaration (EPD), Sustainability Action Plan, ESG/CSR, ISO 14001 Environmental Management System (EMS)
Emissions
105% Cradle to Gate (A1-A3)
GWP Functional Unit
kg CO2e/m2
Ecosystem Health
Ecosystem Health
ISO 14001 Environmental Management System (EMS)
Social Health & Equity
Organizational Commitments
UN Global Compact, ISO 14001
Social Equity Impact
UN Global Compact
Sustainability Action Plan
ESG/CSR
Circular Economy
Circular Economy
Environmental Product Declaration (EPD), Health Product Declaration (HPD)
