Roppe Armour Multi-Use Rubber Tile | Product

Core Specs

General Information

Collection Name: Armour
Color Name: Black
Color Number: 100
Manufacturer SKU: JJ9931P100
Price Range: $$
Product Name: Armour Multi-Use Rubber Tile
Warranty: 5 Year Limited Commercial Warranty

Material & Finish

Content: Rubber
Format: Modular

Availability & Procurement

Availability: Unavailable
Country Of Origin: United States
Manufacturing Location: Fostoria, OH

Technical Specifications

Length: 4.1
Overall Thickness: 6.3
Size: 19-11/16 in x 19-11/16 in (50 cm x 50 cm)

Applications & Usage

Application Filter: Flooring|Flooring/Flooring for Radiant Heat Systems|Recreation & Sport|Recreation & Sport/Gymnasium
Installation: Armour Multi-Use Flooring material is intended to be installed in a traditional point to point method or ashlar (brick, stacked) method with directional arrows on the back facing the same direction. Material is lot controlled and material from different lot control numbers should not be combined unless shade variation is deemed acceptable. Refer to Installation attachment for details

Performance Metrics

Abrasion Wear Resistance: ASTM D3389 - Excellent, = 1 g loss (after 1000 cycles)
Acoustics: ASTM E2179 Sound Reduction - ?IIC 9 (6 in Concrete Slab); ASTM E492 Impact Insulation Class - IIC 51 (6 in Concrete Slab / Ceiling Assembly); ASTM E90 Sound Transmission Class - STC 63 (6 in Concrete Slab / Ceiling Assembly)
Classification: ASTM F1344 Rubber Floor Tile - Type I, A, Grade 1
Flammability: ASTM E648 (NFPA 253) Critical Radiant Flux - Class 1, = 0.45 W/cm²; ASTM E662 (NFPA 258) Smoke Density - Passes, = 450
Hardness: ASTM D2240 Durometer Hardness Indention = 85 Shore A
Light Blocking: Unknown
Maintenance: Refer to Maintenance attachment for details
Slip Resistance: ASTM D2047 Static Coefficient of Friction = 0.50

Sustainability

Human Health

Human Health Impact: Phthalates free, SCS Global FloorScore Certified, Health Product Declaration (HPD), WELL Compliant, Antimicrobial free, Halogenated Flame Retardants Free, PFAS free
VOC Emissions Testing Methodology: CDPH / CHPS 01350 Compliant

Climate Health

Emissions: TVOC Emissions 0.5 mg/m³
GWP Functional Unit: kg CO2e/m2

Social Health & Equity

Sustainability Action Plan: Sustainability Action Plan

Certifications & Disclosures

Disclosure Level: 100 ppm
Environmental Product Declaration: Product-Specific EPD
Ingredient Disclosure: Health Product Declaration (HPD)
LEED: Contributes to LEED v4/4.1 Requirements
VOC Emissions Testing Certificate: FloorScore Certified
