Surpasses ASTM F2199 - Less than or equal to 0.020in/linear foot
Edge End
Micro-Bevel
Overall Thickness
2.5
Size
4in x 24in (101.6mm x 609.6mm)
Wear Layer Thickness
22mil (0.55mm)
Applications & Usage
Application Filter
Flooring
Installation
Glue Down. Refer to Installation attachment for details
Performance Metrics
Abrasion Wear Resistance
ASTM D4060 - Greater than or equal to 20,000 cycles (varies with emboss)
Acoustics
ASTM E2179 & ASTM E989 - Delta IIC 21, Delta IIC 14 (6in concrete slab). Refer to Technical Data attachment for details
Classification
ASTM F1700, Class lll, Type B
Color Stability From Heat
Surpasses ASTM F1514 - Average & Max Delta E <8.0
Compression
Surpasses ASTM F1914 Residual Indentation - Average <8%, Maximum less than or equal 10%; Passes ASTM F970 Static Load - ±0.005in, 250 lbs load; SIM Test Static Load Limit - Greater than or equal to 1,000 lbs
Flammability
Passes ASTM E648 Radiant Panel - Class l, Greater than or equal to 0.45 w/cm2; ASTM E662 Smoke Density - Flaming & Non-Flaming, Less than or equal to 450; CAN/ULC S.101.2-10 - FSR less than or equal to 15, SDC less than or equal to 150
Flexural Strength
Surpasses ASTM F137 - No cracks/breaks (1in/25.4mm Mandrel)
Light Blocking
Complete
Lightfastness
Surpasses ASTM F1515 - Average & Max Delta E <8.0
Maintenance
Refer to Maintenance attachment for details
Slip Resistance
Passes ASTM D2047 Coefficient of Friction - Greater than or equal to 0.6 Dry
