Surpasses ASTM F2199 - Less than or equal to 0.020in/linear foot
Edge End
Micro-Bevel
Overall Thickness
3.2
Size
24in x 24in (609.6mm x 609.6mm)
Wear Layer Thickness
28mil (0.7mm)
Applications & Usage
Application Filter
Flooring
Installation
Glue Down. Refer to Installation attachment for details
Performance Metrics
Abrasion Wear Resistance
ASTM D4060 - Greater than or equal to 20,000 cycles
Acoustics
ASTM E90 - STC 51, ASTM E492 - IIC 50, ASTM E2179 - IIC 21 (6in concrete slab). Refer to Technical Data attachment for details
Classification
ASTM F1700, Class lll, Type B
Color Stability From Heat
Surpasses ASTM F1514 - Average Delta E <8.0
Compression
Surpasses ASTM F1914 Residual Indentation - Average <8%, Maximum less than or equal 10%; Passes ASTM F970 Static Load - ±0.005in, 250 psi; SIM Test Static Load Limit - Greater than or equal to 1,000 lbs
Electrical Resistance
ANSI ESD STM97.2 Body Voltage - Average (Abs) Less than or equal to 2.0kV
Flammability
Passes ASTM E648 Radiant Panel - Class l, Greater than or equal to 0.45 w/cm2; ASTM E662 Smoke Density - Flaming & Non-Flaming, Less than or equal to 450; CAN/ULC S.101.2-10 - FSR less than or equal to 45, SDC less than or equal to 250
Flexural Strength
Surpasses ASTM F137 - No cracks/breaks (1in/25.4mm Mandrel)
Light Blocking
Complete
Lightfastness
Surpasses ASTM F1515 - Average Delta E <8.0
Maintenance
Refer to Maintenance attachment for details
Slip Resistance
Passes ASTM D2047 Coefficient of Friction - Greater than or equal to 0.6 Dry
