Basic Black Hautelink

Name: Basic Black Hautelink
Brand: Nevamar
SKU: 100434094

Nevamar

Laminate

Overnight

Commercial & Residential

Order sample

Basic Black Hautelink

Sample size: 5 in x 4 in x 0 in

Arrives tomorrow

Core Specs

General Information

Collection Name: Fire Rated HPL
Manufacturer SKU: HLT001
Price Range: $
Product Name: Basic Black Hautelink
Subbrand Name: Panolam
Warranty: 1 year limited warranty
Manufacturer Notes: This material cannot be post formed and should not be exposed to extreme humidity, continuous sunlight, or temperatures above 275°F (135°C) for extended periods of time

Material & Finish

Construction: Manufactured in a flat press by laminating kraft paper saturated in melamine resin with phenolic-impregnated kraft layers at high pressure and heat. Panels are trimmed to size and the backs are sanded to facilitate bonding to a substrate. Material thickness is determined by the number of kraft layers bonded together. The surface layer has been designed to be non-absorbent and dry erase compatible
Content: Layers of melamine-saturated decorative kraft paper with a dry erase surface laminated to a phenolic-impregnated kraft paper core
Finish: Armored Protection (finish code: T) comes standard
Format: Panel / Sheet

Availability & Procurement

Availability: Typically Stocked, Limited Stock, Made to Order / Special Order, Stocked in North America
City Of Origin: Auburn
Country Of Origin: United States
Custom Capabilities: Fire Rated grades are only manufactured with a brown phenolic core. Other widths and thicknesses are available upon request

Technical Specifications

Dimensional Stability: Tested to standard NEMA/LD 3-2005 for dimensional change. Results varied between 0.25% - 0.40% in the machine direction and 0.70% - 0.80% in the cross direction, depending on product type and thickness.
Edge End: Edges should be filed smooth and oriented towards the substrate to help prevent stress cracks and to minimize chipping
Impact Resistance: Tested to standard NEMA/LD 3-2005 for ball impact resistance. Results varied between 25in-60in depending on product type and thickness.
Overall Thickness: 61
Product Features: Customizable
Size: 36in x 96in, 36in x 120in, 36in x 144in, 48in x 96in, 48in x 120in, 48in x 144in, 60in x 96in, 60in x 120in, 60in x 144in

Applications & Usage

Application Filter: Wall
Installation: Use carbide-tipped blades and router bits for cutting purposes. Keep feed rates slow and tool speed high. The inside corners of cutouts should have a minimum radius of 0.125in and be filed smooth. When fasteners are required, it is advisable to drill an oversized hole through the laminate first. These strategies reduce the likelihood of stress cracks. Refer to the Postforming Technical Bulletin for postforming guidance
Recommended Adhesive: Maximum performance is gained by using a fire-rated adhesive
Suitable Substrates: Medium to high density fiberboard, particleboard, or metals are suitable substrate options. Do not glue directly to plaster walls, gypsum wallboard, or concrete. The use of a backing sheet is recommended to minimize warpage. Apply to the opposite side of the substrate. The thickness of the backing sheet should be relatively equal to the thickness of the decorative laminate on the face of the assembly.

Performance Metrics

Abrasion Wear Resistance: Tested to standard NEMA/LD 3-2005 for wear resistance. Result of 1,000 cycles with Armored Protection finish. Results may differ with other finishes
Flammability: Tested to standard ASTM E84 and CAN/ULC-S102-M. Results dependent on the HPL product type, bonding substrate, and adhesive. See Technical Bulletin for additional information
Light Blocking: Complete
Lightfastness: Tested to standard NEMA/LD 3-2005 for light resistance. Resulted in no effects
Maintenance: Clean using a felt or multi-purpose board eraser. Use over-the-counter Marker Board cleaning products or a solution of alcohol and water when additional cleaning measures are necessary. After extended use, solvents from dry erase markers may form a film on the surface, creating a ghosting effect. A similar effect may occur if the marker is erased before it is completely dry. Additional causes of ghosting may be adhesive residue left behind by protective peel coat, tapes, and post papers. Marks left by inadvertent use of a permanent marker can often be removed by tracing over the mark with a dry erase marker then immediately wiping off both inks. Permanent marker can also be removed using nail polish remover. Many commercially available products contain substances that may damage or discolor a laminate surface. This material has a high gloss finish so abrasive cleaners that may scratch the surface are not recommended. Avoid cleaners with harsh chemicals
Stain Resistance: Stain 1-10 No Effect, Stain 11-15 No Effect (NEMA/LD 3-2005 3.4)
Water Resistance: Tested to standard NEMA/LD 3-2005 for boiling water resistance. Resulted in no effects.

Sustainability

Human Health

Human Health Impact: CDPH Standard Method v1.2-2017, Low Emitting/Low VOC, UL GREENGUARD, UL GREENGUARD GOLD, Declare Product Label - LBC Red List Approved
VOC Emissions Testing Methodology: CDPH / CHPS 01350 Compliant

Climate Health

Climate Impact: CARB Compliant
Emissions: Low emitting

Ecosystem Health

Ecosystem Health: Forest Stewardship Council (FSC) Certified - Chain of Custody

Social Health & Equity

Social Equity Impact: Forest Stewardship Council (FSC) Certified, Forest Stewardship Council (FSC) Certified - Chain of Custody

Circular Economy

Circular Economy: Forest Stewardship Council (FSC) Certified, Declare Product Label - LBC Red List Approved

Certifications & Disclosures

LEED: May contribute to LEED credits
