Also available in made-to-order sizes and finishes. Inquire with brand or local brand representative
Technical Specifications
Dimensional Stability
Postforming grade laminate is hygroscopic and therefore capable of absorbing moisture from the atmosphere. Grade 12 (HGP) = 1.1% (max) change in both Machine and Cross Directions. Grade 20 (VGP) = 1.4% (max) change in both Machine and Cross Directions.
Impact Resistance
Resistant to scratches and impacts under normal use conditions.
Length
4
Overall Thickness
20
Product Features
Customizable
Size
The most common sheet sizes are 4x8,10 ft, 5x10,12 ft, and 2.5x12 ft. Please reach out to your local Formica representative regarding made-to-order sizes and finishes
Contact, semi-rigid (PVAc), or rigid (urea, resorcinol) adhesives may be used, following the adhesive manufacturer’s recommendations.
Suitable Substrates
Adhere to MDF or #45 density particleboard. Do not apply directly to plaster, drywall (gypsum board), or concrete. Refer to the Substrate Tech Guide for additional information.
Performance Metrics
Abrasion Wear Resistance
ANSI/NEMA LD3 3.13 Tested - Minimum = 400 Cycles
Flammability
Passes FMVSS 302; Not ASTM E84 rated (ASTM E84 rated grades are available)
Flexural Strength
Grade 12 (HGP) has a minimum bend radius of 1/2" (12.7 mm) for outer edges and 3/16" (4.8 mm) for cove radii. Grade 20 (VGP) has a minimum bend radius of 3/8" (9.5 mm).
Low Emitting/Low VOC, Precautionary List Free, UL GREENGUARD, UL GREENGUARD GOLD, CDPH Standard Method v1.2-2017, Declare Product Label - LBC Red List Approved, Health Product Declaration (HPD), RoHS Compliant
VOC Emissions Testing Methodology
CDPH / CHPS 01350 Compliant
Climate Health
Climate Impact
EC3, Environmental Product Declaration (EPD), Life Cycle Assessment (LCA)
Emissions
A low-emitting material per GREENGUARD evaluation
Ecosystem Health
Ecosystem Health
Forest Stewardship Council (FSC) Certified|Forest Stewardship Council (FSC) Certified - Chain of Custody
Social Health & Equity
Social Equity Impact
Forest Stewardship Council (FSC) Certified, Build America, Buy America Act (BABAA) Compliant, Forest Stewardship Council (FSC) Certified - Chain of Custody, Made in USA
Circular Economy
Circular Economy
Health Product Declaration (HPD), Forest Stewardship Council (FSC) Certified, EC3, Recycled Content - Post-Consumer, Declare Product Label - LBC Red List Approved, Environmental Product Declaration (EPD), Recycled Content, Recycled Content - Pre-Consumer, USDA Certified Biobased Product
