Limited warranty for one year from the date of purchase
Material & Finish
Construction
High Pressure Laminate
Content
Kraft Paper, Melamine Resin, Phenolic Resin
Finish
Stain Touch (Finish Code: 11)
Format
Panel / Sheet
Availability & Procurement
Availability
Typically Stocked
Country Of Origin
United States
Custom Capabilities
Also available in made-to-order sizes and finishes. Inquire with brand or local brand representative
Technical Specifications
Dimensional Stability
Postforming grade laminate is hygroscopic and therefore capable of absorbing moisture from the atmosphere. Grade 12 (HGP) = 1.1% (max) change in both Machine and Cross Directions.
Edge End
Standard square edges are flat with visible seam line. IdealEdge® Decorative Edging options available by request
Impact Resistance
Resistant to scratches and impacts under normal use conditions.
Length
4
Overall Thickness
12
Product Features
Customizable
Size
The most common sheet sizes are 2.5x8,10,12 ft, 4x8 ft, and 5x12 ft. Please reach out to your local Formica representative for additional infromation on made-to-order (MTO) sizes and finishes
Total Weight
Grade 12 = 0.252 lbs/sqft
Applications & Usage
Application Filter
Countertop|Kitchen|Furniture
Recommended Adhesive
Contact, semi-rigid (PVAc), or rigid (urea, resorcinol) adhesives may be used, following the adhesive manufacturer’s recommendations.
Suitable Substrates
Adhere to MDF or #45 density particleboard. Do not apply directly to plaster, drywall (gypsum board), or concrete. Refer to the Substrate Tech Guide for additional information.
Performance Metrics
Abrasion Wear Resistance
ANSI/NEMA LD3 3.13 Tested - Minimum = 400 Cycles
Flammability
ASTM E84 - Class 1, FMVSS 302
Flexural Strength
Grade 12 (HGP) has a minimum bend radius of 1/2" (12.7 mm) for outer edges and 3/16" (4.8 mm) for cove radii.
UL GREENGUARD, Precautionary List Free, CDPH Standard Method v1.2-2017, Declare Product Label - LBC Red List Approved, Low Emitting/Low VOC, RoHS Compliant, UL GREENGUARD GOLD, Health Product Declaration (HPD)
VOC Emissions Testing Methodology
CDPH / CHPS 01350 Compliant
Climate Health
Climate Impact
Environmental Product Declaration (EPD), EC3, Life Cycle Assessment (LCA)
Emissions
A low-emitting material per GREENGUARD and GREENGUARD GOLD evaluation. Formaldehyde may be released in minute but detectable amounts when material is shipped/stored in bulk quantities or during sanding/cutting/machining operations
Ecosystem Health
Ecosystem Health
Forest Stewardship Council (FSC) Certified|Forest Stewardship Council (FSC) Certified - Chain of Custody
Social Health & Equity
Social Equity Impact
Forest Stewardship Council (FSC) Certified, Made in USA, Build America, Buy America Act (BABAA) Compliant, Forest Stewardship Council (FSC) Certified - Chain of Custody
Circular Economy
Circular Economy
EC3, Recycled Content, Recycled Content - Post-Consumer, USDA Certified Biobased Product, Forest Stewardship Council (FSC) Certified, Recycled Content - Pre-Consumer, Declare Product Label - LBC Red List Approved, Environmental Product Declaration (EPD), Health Product Declaration (HPD)
