Limited warranty for one year from the date of purchase
Material & Finish
Construction
High Pressure Laminate
Content
Kraft Paper, Metal Foil, Phenolic Resin
Finish
Homapal (Finish Code: 99)
Format
Panel / Sheet
Availability & Procurement
Availability
Typically Stocked
Country Of Origin
United States
Custom Capabilities
Also available in sizes and finishes. Inquire with brand or local brand representative
Lead Time
2-3 days for transit of stocked material. Make to Order items can take 10 days
Technical Specifications
Edge End
Edges and corners should be routed, sanded or filed smooth and free of chips or nicks. Cut or milled edges should be finished with a fine file or abrasive paper to remove any burrs
Overall Thickness
0.05
Product Features
Customizable
Size
This product comes in 4x8 ft and 4x10 ft. Please reach out to your local Formica representative for additional information
Can be sawed, drilled, routed, and fabricated using carbide-tipped cutting tools. Always cut with the decorative surface face up. Cold post-forming and bending can be completed with sheet metal fabrication techniques. Sheet metal brakes and pipe rollers can be used to shape the metal prior to bonding to substrates
Suitable Substrates
45# density, industrial grade particleboard or Medium Density Fiberboard (MDF). MDF is recommended for mirror finishes to minimize telegraphing. Do not use drywall (gypsum), plaster, concrete, solid lumber, bending plywood or underlayment. Critical applications requiring a well-balanced panel assembly, such as cabinet doors, should use the same material on both sides to minimize warpage. Less critical assemblies may require only a cabinet liner or phenolic backer.
Performance Metrics
Flammability
ASTM E84 - Class A
Light Blocking
Complete
Maintenance
Damp cloth and mild detergent
Sustainability
Human Health
Human Health Impact
Health Product Declaration (HPD), UL GREENGUARD GOLD, Halogenated Flame Retardants Free, Low Emitting/Low VOC, RoHS Compliant, UL GREENGUARD
VOC Emissions Testing Methodology
CDPH / CHPS 01350 Compliant
Climate Health
Climate Impact
EC3, Life Cycle Assessment (LCA), Environmental Product Declaration (EPD)
Emissions
TVOC - 0.22 mg/m3
Social Health & Equity
Social Equity Impact
Build America, Buy America Act (BABAA) Compliant
Circular Economy
Circular Economy
EC3, Environmental Product Declaration (EPD), Health Product Declaration (HPD)
