Milliken Circuit | Product

Core Specs

General Information

Collection Name: Common Factor 2
Color Name: Black
Color Number: CIR180-174-19
Manufacturer SKU: 2710039298
Price Range: $$
Product Name: Circuit
Warranty: Lifetime Warranty. Refer to Warranty attachment for details

Material & Finish

Backing: WellBAC® Comfort Plus
Carpet Fiber Type: Type 6 6 Nylon
Construction: Tufted, Textured Loop
Content: Milliken-Certified WearOn® Nylon
Dye Method Filter: Digital Dye Injection / Printed
Finish: StainSmart®
Format: Modular

Availability & Procurement

Availability: Quick Ship
City Of Origin: LaGrange
Country Of Origin: United States
Custom Capabilities: Available with TractionBack®
Lead Time: 3 Weeks
Manufacturing Location: La Grange, GA

Technical Specifications

Carpet Pile Height: Finished Pile Height - 0.14 in (3.56 mm); Finished Pile Thickness - 0.11 in (2.79 mm)
Length: 39.4
Overall Thickness: 8.9
Pile Face Weight: 678.1
Product Features: Customizable
Yarn Tuft Details: 1/10 Gauge, 10.3 SPI, 103/sq in (1,595/100 sq cm) Tufts

Applications & Usage

Application Filter: Flooring
Installation: Refer to Installation PDF for more details
Installation Direction: Monolithic

Performance Metrics

Crocking: AATCC 165 ≥ 4.0 Wet or Dry
Durability: Contract (Severe Traffic)
Electrostatic Propensity: AATCC 134 Static Electricity (20% R.H.,70° F) ≤ 3.5 kV, Permanent Conductive Fiber
Flammability: ASTM E648 Radiant Panel - = 0.45 (Class I); ASTM E662 or NFPA 258-T Smoke Density - = 450; ASTM D2859 or CPSC FF-1-70 Methenamine Pill Test - Self-Extinguishing
Light Blocking: Unknown
Lightfastness: AATCC 16E = 4.0 at 80 Hours
Maintenance: MilliCare® Textile and Carpet Care Service Network
Surface Pile Density: 7793

Sustainability

Human Health

VOC Emissions Testing Methodology: CDPH / CHPS 01350 Compliant

Climate Health

Emissions: TVOC Range - 0.5 mg/m³ or less
GWP Functional Unit: kg CO2e/m2
LCA Optimization Plan: false

Social Health & Equity

Organizational Commitments: Carbon Disclosure Project, ISO 14001, Science Based Targets Initiative (SBTI)
Sustainability Action Plan: Sustainability Action Plan

Certifications & Disclosures

Disclosure Level: 100 ppm
Environmental Product Declaration: Product-Specific EPD
Ingredient Disclosure: Health Product Declaration (HPD)
LEED: May contribute to LEED credits
VOC Emissions Testing Certificate: CRI Green Label Plus
