Intended for commercial and multi-unit residential project specification only.
Warranty
Lifetime Warranty
Manufacturer Notes
Quick Ship Color Options - DIS49-Marine, DIS57-Smoke, DIS59-Raven
Material & Finish
Backing
Nexus Modular
Carpet Fiber Type
Type 6 Nylon
Construction
Patterned Loop
Content
Encore SD Ultima (with recycled content)
Dye Method Filter
Solution Dyed
Finish
ProTex® Soil Release
Format
Modular
Availability & Procurement
Availability
Typically Stocked, Quick Ship, Stocked in North America
Country Of Origin
United States
Custom Capabilities
Available with alternative backing(s): Nexus Cushion, Nexus FC Cushion, Advance Modular; Alternative fiber types(s): TypeEncore 100 (100% recycled content); Alternative adhesive(s): TileTabs
Manufacturing Location
Dalton, Georgia, USA
Technical Specifications
Length
24
Overall Thickness
0.228
Pile Face Weight
475
Product Features
ADA Compliant
Yarn Tuft Details
1/12 Gauge (4.72 rows per cm), 9.70 SPI (9.70 stitches/in)
Applications & Usage
Application Filter
Flooring
Installation
Commercialon Premium Modular and LVT Adhesive (Optional Adhesive TileTabs Available)
Installation Direction
Monolithic, Quarter Turn, Ashlar, Brick
Recommended Adhesive
Commercialon Premium Modular and LVT Adhesive
Performance Metrics
ADA
Compliant For Accessible Routes
Flammability
ASTM E648 Flooring Radiant Panel - Class 1; ASTM E662 Smoke Density <450 (Flaming), ASTM D 2859 (Pill -Surface Flammability)
Light Blocking
Complete
Lightfastness
Yes
Surface Pile Density
5793 oz/cubic yard (214.81 kg/cubic meter)
Sustainability
Human Health
Human Health Impact
CDPH Standard Method v1.2-2017, CRI Green Label Plus Indoor Air Quality, Health Product Declaration (HPD), Low Emitting/Low VOC, Halogenated Flame Retardants Free, PFAS free, Formaldehyde Free, Global Reporting Initiative (GRI), Declare Product Label - LBC Red List Free
VOC Emissions Testing Methodology
CDPH / CHPS 01350 Compliant
Climate Health
Climate Impact
NSF/ANSI 140 Certified Carpet - Compliant, Environmental Product Declaration (EPD), ISO 14001 Environmental Management System (EMS), Sustainability Action Plan, 100% Recyclable, NSF/ANSI 140 Certified Carpet - Gold, Life Cycle Assessment (LCA), EC3, CARB Compliant, ESG/CSR, ISO 14025 Type III environmental declaration programmes, Product-Specific EPD, Global Reporting Initiative (GRI)
Emissions
TVOC - 0.5 mg/m3 or less
GWP Functional Unit
kg CO2e/m2
LCA Optimization Plan
true
Ecosystem Health
Ecosystem Health
ISO 14001 Environmental Management System (EMS)
Social Health & Equity
Organizational Commitments
ISO 14001
Social Equity Impact
Global Reporting Initiative (GRI)
Sustainability Action Plan
Sustainability Action Plan, ESG/CSR
Circular Economy
Circular Economy
Environmental Product Declaration (EPD), Health Product Declaration (HPD), Recycled Content - Pre-Consumer, Manufacturer Take-Back Program, NSF/ANSI 140 Certified Carpet - Compliant, Recycled Content, EC3, Product-Specific EPD, 100% Recyclable, NSF/ANSI 140 Certified Carpet - Gold, Third-Party Partnership for Recovery and Cycling, Declare Product Label - LBC Red List Free
