StaticWorx Eclipse Electrically Conductive (EC) Rubber Tile | Product

Core Specs

General Information

Collection Name: Eclipse
Color Name: Largo
Manufacturer SKU: 2-1124
Price Range: $$$$$
Product Name: Eclipse Electrically Conductive (EC) Rubber Tile
Warranty: Lifetime Warranty
Manufacturer Notes: This product is free of plasticizers

Material & Finish

Construction: Solid Rubber
Content: Two-layer, vulcanized conductive rubber with high quality natural and industrial rubber components
Format: Modular, Roll

Availability & Procurement

Availability: Unavailable

Technical Specifications

Overall Thickness: 2
Size: Tile: 24 in x 24 in; Sheet: 4 ft x 39.8 ft

Applications & Usage

Application Filter: Flooring|Flooring/Electrostatic Dissipative Flooring
Installation: Used with Eclipse EC rubber, DryFix is an ideal adhesive for ESD flooring installations in labs and cleanrooms. Eclipse tiles and roll goods work as both a floor and cove base. Seams can be welded for a seamless installation, creating a dirt and particle-free lab/cleanroom environment. Because there are no wet or messy adhesives to deal with, DryFix can be installed 24/7 with minimal downtime. And the new floor can be used or walked on immediately after installation, minimizing costly production losses. Refer to Installation Instructions PDF for more details

Performance Metrics

Abrasion Wear Resistance: ASTM D 3389 Taber abrasion test - H-18 wheel, 500 gram load, 1000 cycles, gram weight loss not greater than 0.70
ADA: ADA Compliant
Flammability: ASTM E 648; NFPA 253; NBSIR 75 950 result to be not less than 0.45 watts per square centimeter, Class 1; ASTM E 662; NFPA 258; NBS smoke density, less than 450; Solder burn resistant
Hardness: ASTM D2240 - Shore A, not less than 85
Light Blocking: Complete
Maintenance: Unlike some floors that require regular stripping, waxing or polishes, EclipseEC rubber requires only washing with soap and water. Refer to Maintenance Guidelines PDF for more details
Slip Resistance: ASTM D 2047 Static coefficient of friction (James Test) - equal to or greater than 0.6

Sustainability

Human Health

Human Health Impact: CDPH Standard Method v1.2-2017, Halogenated Flame Retardants Free, Low Emitting/Low VOC, PVC free, UL GREENGUARD, UL GREENGUARD GOLD
VOC Emissions Testing Methodology: CDPH / CHPS 01350 Compliant

Certifications & Disclosures

LEED: May contribute to LEED Credits
VOC Emissions Testing Certificate: UL Greenguard Certified or Gold
