Three-layer system - no wax urethane finish top, clear commercial wear layer, decorative print film layer, Patented Recycled Composite Underlayment with Interlocking Tabs
Content
Bio-based polymers and natural minerals, 80% rapidly renewable content
Format
Modular
Availability & Procurement
Availability
Unavailable
Country Of Origin
United States
Lead Time
Contact your rep for more information
Order Increments
2.38 sq ft/tile (0.22 sq meter/tile); 10 tiles per box; 23.8 sq ft per box
Technical Specifications
Overall Thickness
8.6
Size
18.5 in x 18.5 in (47 cm x 47 cm) (nominal)
Total Weight
5.8 lbs/ tile
Applications & Usage
Application Filter
Flooring
Installation
Interlocking
Suitable Substrates
EcoLock™ is a free-lay system that does require adhesives and may be installed over concrete, wood, asbestos tile, rubber, vinyl composite tiles and other standard flooring.
Performance Metrics
Abrasion Wear Resistance
ASTM D-3389 - <0.01 gram weight loss
Acoustics
ASTM E2179 Delta IIC 18
Flammability
ASTM E-648 Critical Radiant Flux - > 0.45 W/cm2 Meets Class I Fire Rating; ASTM E-662 Smoke Density - =450
Maintenance
Refer to Maintenance Guide PDF attachment for details
Slip Resistance
ASTM D-2047 Coefficient of Friction Conforms to ADA Recommendations - 0.92
