Unika Vaev recommends compliance with National Construction Codes and Building Safety Standards. Certification by a qualified practicing structural engineer, such as a Structural Safety Certificate should be confirmed for all overhead installations including baffles
Material & Finish
Content
100% PET (60% Recycled PET)
Availability & Procurement
Availability
Made to Order / Special Order
Custom Capabilities
Custom Sizes: Ecoustic® baffles can be fabricated to client specifications, in lengths from 23 5/8 in to 106 19/64 in and depths from 3 15/16 in to 47 1/4 in. A small range of standard shapes is also available; Custom thicknesses (0.35 in, 0.53 in, 0.98 in) available upon request
Lead Time
5-7 weeks
Technical Specifications
Product Features
Customizable
Size
106 in (L) x 11.8 in (H) x 0.47 in or 0.94 in (D) per baffle fin
Applications & Usage
Application Filter
Ceiling
Installation
Ecoustic® Baffle is a complete system and the lightweight acoustic panels are simple to install. Instyle has a range of proprietary cable suspension systems supplied with natural or black anodized aluminum extrusions. Alternative extrusion fixings to support the baffles can be sourced
Performance Metrics
Acoustics
NRC Rating: 0.45 - 0.95 depending on thickness and spacing
Light Blocking
Complete
Maintenance
Regular Care: Protect from direct heat and sunlight. To prevent dust build up, lightly dust with a soft cloth or vacuum with a soft brush attachment
Sustainability
Human Health
Human Health Impact
Cradle to Cradle Certified - Bronze, Halogenated Flame Retardants Free, Oeko-Tex Certified, Declare Product Label, Health Product Declaration (HPD), Low Emitting/Low VOC, Precautionary List Free, Cradle to Cradle Material Health Certificate - Bronze
VOC Emissions Testing Methodology
CDPH / CHPS 01350 Compliant
Climate Health
Climate Impact
Environmental Product Declaration (EPD), Cradle to Cradle Certified - Bronze, ISO 14001 Environmental Management System (EMS)
Ecosystem Health
Ecosystem Health
ISO 14001 Environmental Management System (EMS)|Cradle to Cradle Certified - Bronze
Social Health & Equity
Organizational Commitments
ISO 14001
Social Equity Impact
Cradle to Cradle Certified - Bronze
Circular Economy
Circular Economy
Health Product Declaration (HPD), Designed for Disassembly, Reuse, and Recycling, Recycled Content, Environmental Product Declaration (EPD), Declare Product Label, Cradle to Cradle Certified - Bronze
Certifications & Disclosures
Disclosure Level
100 ppm
Ingredient Disclosure
Declare Product Label, Health Product Declaration (HPD)
