Ecoustic Chamfer Panel

General Information

Designer Name

Instyle Design Studio

Manufacturer SKU

ECOUSTIC-CHAMFER-PANEL

Price Range

$

Product Name

Ecoustic Chamfer Panel

Manufacturer Notes

On-site trimming of non-chamfered edges is recommended to ensure panels are square. Variations in thickness, fiber composition, color, flecks, and minor surface imperfections are inherent to the material and may occur between panels. Installation may require on-site adjustments by the contractor to achieve a professional finish with minimal variation. Acoustic performance test results are provided as guidelines only

Material & Finish

Content

100% PET (60% Recycled PET)

Availability & Procurement

Availability

Made to Order / Special Order

Technical Specifications

Size

0.47 in Panel: 47.25 in (W) x 106.3 in (H) 0.47 in (D); 0.94 in Panel: 47.25 in (W) x 106.3 in (H) x 0.94 in (D)

Total Weight

7.9 oz/sq ft (2400 gsm +/- 10%)

Applications & Usage

Application Filter

Ceiling|Partition|Wall

Installation

Refer to Installation & Care PDF for details

Performance Metrics

Acoustics

NRC Rating: 0.40 - 0.95 depending on thickness and application

Light Blocking

Complete

Maintenance

Regular Care: Protect from direct heat and sunlight. To prevent dust build up, lightly dust with a soft cloth or vacuum with a soft brush attachment

Human Health

Human Health Impact

Declare Product Label, Halogenated Flame Retardants Free, Cradle to Cradle Material Health Certificate - Bronze, Precautionary List Free, Health Product Declaration (HPD), Oeko-Tex Certified, Low Emitting/Low VOC, Cradle to Cradle Certified - Bronze

VOC Emissions Testing Methodology

CDPH / CHPS 01350 Compliant

Climate Health
