10 year warranty; Excludes kinetic or custom applications.
Material & Finish
Construction
Interlnked rings
Content
100% UV Stabilised Makrolon® Polycarbonate
Opacity Level Openness
The visual open area is approximately 25%. The physical open area is approximately 80%. This means air compliant movement can be maintained in interior spaces
Availability & Procurement
Availability
Made to Order / Special Order
Country Of Origin
New Zealand
Custom Capabilities
Kaynemaile Framed Screens are designed to fit into framed openings and work perfectly in doors, windows and cabinetry. Kaynemaile architectural mesh is a patented, world-leading innovation. The modern chainmail fabric consists of interlinked polycarbonate rings formed seamlessly to create a strong yet highly flexible mesh sheet—with no joins or seams. Kaynemaile Framed Screens are ideal for interior partitions or room dividers in office workplaces, hospitality, retail, hotels and events
Lead Time
Lead times are confirmed on quotation. Expect 3-6 weeks depending on application
Manufacturing Location
New Zealand
Technical Specifications
Diameter
1.1
Impact Resistance
Astron burst testing with a point load area of approx. 32 mm (1.5 in) on small 140 x 140 mm (5.5 in x 5.5 in) samples show a peak resistance of 279 kg (615 lbs)
Product Features
Customizable
Size
Kaynemaile mesh screens are not restricted by panel size - screens can be made to any height or width without joins or gaps
Framed screens are designed to fit within millwork or an outer frame or structure and do not require specialized personnel. Anodized aluminum track is supplied for all four sides of the screen. The screens are supplied ready to install including anodized aluminum track
Performance Metrics
Light Blocking
By protecting the building from harsh sunlight and not restricting the cooling effects of air movement, building engineers can reduce the air conditioning design and system costs, as well as reducing the total energy consumption costs in hot climates
Maintenance
In interior settings, clean with a soft brush, vacuum cleaner mounted brush, or broom. Rinse with water if heavily soiled. For exterior environments, a mild detergent pre-soak followed by a low-pressure water blaster rinse (no more than 1200psi) is best. If pressure blasting isn’t possible, then clean with a soft brush or broom and water. Regardless of location, avoid harsh soaps, solvents, chemicals or waxes to clean the product as these may cause damage and void the warranty
Tensile Strength
The accumulated strength of seamless mesh increases proportionately with the size of the panel
Sustainability
Human Health
Human Health Impact
Low Emitting/Low VOC, Zero VOC
VOC Emissions Testing Methodology
CDPH / CHPS 01350 Compliant
Climate Health
Climate Impact
100% Recyclable, ISCC Certified, Life Cycle Assessment (LCA)
