Please note that samples are provided for color and pattern selection purposes only and may not represent the complete system construction.
Warranty
1 year from date of installation
Manufacturer Notes
Stonhard offers a range of multilayered flooring systems, with each layer carefully engineered to meet the specific performance requirements of different applications. Please contact your Stonhard Architectural Design & Engineering representative to review the appropriate system build-up for your project. Stonhard offers a variety of sustainability documentation and certifications, including CDPH compliance certificates, Health Product Declarations (HPDs), and Environmental Product Declarations (EPDs). Please contact your Stonhard Architectural Design & Engineering Representative to obtain copies of the applicable documentation for your project.
Material & Finish
Construction
Components are packaged separately and mixed together on-site. Pours of 2mm or above in thickness are self-leveling
Content
A multi-component system consisting of a polymetric primer, an epoxy resin, curing agents, and a finely graded aggregate with highly reflective, decorative flakes and pigments. Refer to Product Data sheet for specifics
Finish
Available in matte, satin, gloss microtexture, or high-gloss finishes, depending on pour thickness. Use of a urethane topcoat is required for 1 mm pours. Refer to manufacturer's documentation for additional information
Format
Poured / Liquid
Availability & Procurement
Availability
Unavailable
City Of Origin
Maple Shade
Country Of Origin
United States
Custom Capabilities
Customize colors, finishes, textures, and patterns. Formulations can be made to meet specific criteria and incorporate unique elements such as pigments, metallics, mica chips, or glitter. Create custom logos or intricate design patterns
State Of Origin
New Jersey
Technical Specifications
Impact Resistance
ASTM D-2794 tetsed. Result of 110 in-lb.
Overall Thickness
2
Product Features
Customizable
Size
Covers approximately 200 sqft per unit
Applications & Usage
Application Filter
Flooring
Installation
A specially trained application crew from parent company Stonhard will complete installation. First, patching, leveling, and priming of the substrate is needed. Components will then be mixed together and uniformly spread over the primed and sealed substrate using a squeegee and roll. A chemical reaction between components causes the mixture to harden. Mix and apply the topcoat sealant material over the hardened floor. Installation can only be completed when the slab and air temperatures are between 65° - 85° F. Relative humidity must be below 80%. Refer to manufacturer's documentation for additional information
Suitable Substrates
With the appropriate primer, concrete, wood or metal are suitable substrates. Due to the material's self-leveling nature, the substrate must be extremely flat and level (Ff/ Fl 50). Not recommended on asphalt, brick, quarry tile, mastic, or painted surfaces.
Performance Metrics
Abrasion Wear Resistance
17% reduction after 100 cycles (F-1679/Soft Scrub) in a scratch resistance test on a high-gloss surface
Hardness
ASTM D-2240, Shore A Durometer hardness tested. Result of 80 - 85
Light Blocking
Complete
Maintenance
It is recommended to use automatic floor scrubbing machines with Stonkleen SR9 at 8 oz dilution per gallon of water, for routine maintenance. A Microfiber mop for periodic removal of dust is advised. General cleaning and clean up of spills can be accomplished using an absorbent cloth or mop. If required, Stonkleen DG2 can be used to remove dirt or deposits. Waxing is required for long-term maintenance of flooring systems with a high-gloss finish. Refer to manufacturer's documentation for additional information
Performance
Has a cure rate of 36 hours at 77°F for foot traffic and light operations. 48 to 72 hours for normal operations
Tensile Strength
ASTM D-638 tested. Result of 800 psi.
Sustainability
Human Health
Human Health Impact
CDPH Standard Method v1.2-2017, Low Emitting/Low VOC, Health Product Declaration (HPD)
