Cube panels are customizable with Print, Mold & Press, Precision Cut, Groove, and Peel ‘n’ Stick, and require no edging or capping
Lead Time
3-5 weeks
Technical Specifications
Impact Resistance
ISO 7892:1988. Hard body: resists 9J (0.5kg/2m); no surface damage. Soft body: resists 70J (50kg/150mm); no damage. Adhered to 10mm plasterboard.
Length
110
Overall Thickness
1
Size
48 in x 96 in
Applications & Usage
Application Filter
Ceiling|Wall
Recommended Adhesive
Water-based spray contact adhesive or solvent contact adhesive, combined with construction adhesive for ceiling and heavier applications. Or adhesive-free using SpinFix™ 100% PET friction-welded mounting clips.
Suitable Substrates
Solid substrates prepared to minimum Level 3 finish; clean, dust-free, dry. All gaps, joins, and cracks taped before installation. Very porous surfaces sealed prior to adhesive application. Gloss/semi-gloss finishes lightly sanded. Wall or ceiling substrate.
Performance Metrics
Acoustics
NRC 0.45 (1/2"); NRC 0.70 (1/2" with 1" air gap); NRC 0.70 (1"); NRC 0.80 (1" with 1" air gap). Min NRC 0.45
Antimicrobial Note
Disinfect with isopropanol or ethanol diluted to 70% with water, or quaternary ammonium compounds. ASTM G21-15 tested: Growth Rating 0 — does not promote growth of molds and mildew.
Crocking
ISO 105-X12:2016 with Dry Rating of 4-5 (Highest = 5) and Wet Rating of 4-5 (Highest = 5)
Flammability
ASTM E84 Class A, FS:0 SD:45 (1/2", test RJ4479-2); Class A FS:0 SD:65 (1", test RJ4479-1); CAN/ULC-S102 (3/8" | 9mm only)
Maintenance
Light vacuuming regularly prevents dust buildup. Clean marks with mild detergent + rinse + blot. Spot clean only; no stiff brush or solvents. Disinfect with 70% isopropanol or ethanol, or quaternary ammonium compounds.
Sustainability
Human Health
Human Health Impact
CDPH Standard Method v1.2-2017, Declare Product Label, Declare Product Label - LBC Red List Free, Low Emitting/Low VOC
Climate Health
Climate Impact
Environmental Product Declaration (EPD), ISO 14001 Environmental Management System (EMS), SCS Carbon Neutral Certification
