Interface Haptic | Product

Core Specs

General Information

Collection Name: Visual Code Collection
Color Name: Natural
Color Number: 106453
Manufacturer SKU: 92740059999WS
Price Range: $$$$
Product Name: Haptic
Warranty: 15 Year Standard Carpet Warranty

Material & Finish

Backing: GlasBac™ (Standard Backing). Additional backing options - CQuest™Bio, CQuest™BioX, CushionBac Renew™
Carpet Fiber Type: Type 6 Nylon
Construction: Tufted Pattern Loop
Content: 100% Recycled Content Nylon (Aquafil)
Dye Method Filter: Solution Dyed
Finish: Protekt²®, Intersept®
Format: Modular

Availability & Procurement

Availability: Made to Order / Special Order
Country Of Origin: United States
Lead Time: Can vary per order. Please contact your sales rep for details
Manufacturing Location: La Grange, GA

Technical Specifications

Carpet Pile Height: Pile Height - 0.15 in (3.8 mm), Pile Thickness - 0.104 in (2.6 mm)
Dimensional Stability: AACHEN Din 54318 <0.10%
Length: 1
Pile Face Weight: 814
Yarn Tuft Details: 1/10 Gauge (39.4 ends/10cm), 8.5 SPI (33.5 ends/10cm)

Applications & Usage

Application Filter: Flooring
Installation: Glue Down. Refer to Installation attachment for details
Installation Direction: Ashlar

Performance Metrics

Durability: Heavy Duty
Electrostatic Propensity: AATCC 134 < 3.0 KV
Flammability: Passes ASTM E648 Radiant Panel; ASTM E662 Smoke Density = 450; Passes Methenamine Pill Test (DOC-FF1-70)
Light Blocking: Complete
Lightfastness: AATCC 16 E = 4.0 @ 60 AFU's
Maintenance: Refer to Maintenance attachment for details
Surface Pile Density: 8,308 oz/yd³ (308,058.8 g/m³)

Sustainability

Human Health

Human Health Impact: Health Product Declaration (HPD)
VOC Emissions Testing Methodology: CDPH / CHPS 01350 Compliant

Climate Health

Climate Impact: UN Global Compact, ISO 14001 Environmental Management System (EMS), NSF/ANSI 140 Certified Carpet - Platinum
GWP Functional Unit: kg CO2e/m2
LCA Optimization Plan: true

Ecosystem Health

Ecosystem Health: ISO 14001 Environmental Management System (EMS)

Social Health & Equity

Organizational Commitments: UN Global Compact, ISO 14001
Social Equity Impact: UN Global Compact
Sustainability Action Plan: ESG/CSR

Circular Economy

Circular Economy: Health Product Declaration (HPD), NSF/ANSI 140 Certified Carpet - Platinum

Certifications & Disclosures

Disclosure Level: 1000 ppm
Environmental Product Declaration: Product-Specific EPD
Ingredient Disclosure: Health Product Declaration (HPD)
LEED: May contribute to multiple IEQ and MR credits
VOC Emissions Testing Certificate: CRI Green Label Plus
