Decorative surface papers impregnated with melamine resins are pressed over Kraft paper core sheets impregnated with phenolic resin. Sheets are bonded together under high pressure and heat. Finished sheets are trimmed and back-sanded to facilitate bonding to substrate
Content
Phenolic resin-impregnated Kraft paper sheets and decorative surface papers impregnated in melamine resin. Post-consumer recycled content percentage: Product Type 335 Vertical Grade Postforming Laminate (VGP) and Product Type 735 Vertical Surface (VGS) = 32%. Product Type 350 Horizontal Grade Postforming Laminate (HGP), 376 Horizontal Grade Postforming Laminate (HGP) and 776 (HGL) = 20%
Finish
67 Aligned Walnut
Format
Panel / Sheet
Availability & Procurement
Availability
Typically Stocked
Country Of Origin
United States
Custom Capabilities
Highly customizable, reach out to your local rep for more information
Technical Specifications
Dimensional Stability
ISO 4586 tested for Dimensional Stability. Product Type Type 107 = 0.3% in the machine direction and 0.7% in the cross direction.
Edge End
Options include beveled, crescent, and mitered edges. Edgebands are also available for cabinets, doors, drawers, shelves, tables, and countertops. Refer to attached documents or contact your local rep for additional information
Impact Resistance
ISO 4586 tested for Impact Resistance. Product Type 107 Horizontal Grade Standard Laminate (HGS ) = 65in.
Overall Thickness
376
Product Features
Customizable
Size
48 in x 144 in, 60 in x 144 in
Total Weight
0.322 lbs/sqft
Applications & Usage
Application Filter
Bath|Countertop|Kitchen|Furniture
Installation
Installation varies depending on application. Refer to Spec Sheet attachment for additional information
Performance Metrics
Abrasion Wear Resistance
ISO 4586 tested for Surface Wear Resistance. Meets or exceeds 400 cycles
Flammability
ASTM E84 tested. Class B result. Consider Wilsonart® Fire-Rated laminates for Class A results. Complies with U.S. Federal Motor Vehicle Safety Standard (FMVSS) 302 (Flammability of Interior Materials). U.S. Military Standard MIL-P-17171E (SHIPS)/Plastic Laminate
Light Blocking
Complete
Lightfastness
ISO 4586 tested for Light Resistance. Slight effect for Type 107 products
Maintenance
To clean the surface, use a damp cloth or sponge and a mild soap or detergent. Rinse thoroughly with warm water and wipe dry. Avoid acidic or abrasive cleaners. A diluted bleach solution can be used as a disinfectant. Reference the Care & Maintenance Guide for additional information
Stain Resistance
ISO 4586 tested for Stain Resistance. No effect from Reagents 1-10. Slight effect from Reagents 11-15
Water Resistance
ISO 4586 tested for Boiling Water Resistance. Slight effect on glossy surfaces. No effect on other finishes.
Sustainability
Human Health
Human Health Impact
CDPH Standard Method v1.2-2017, Declare Product Label, Declare Product Label - LBC Red List Approved, Health Product Declaration (HPD), Low Emitting/Low VOC, SCS Indoor Advantage Certified, SCS Indoor Advantage GOLD, UL GREENGUARD, UL GREENGUARD GOLD
VOC Emissions Testing Methodology
CDPH / CHPS 01350 Compliant
Climate Health
Emissions
Low VOC emissions
Circular Economy
Circular Economy
Declare Product Label, Declare Product Label - LBC Red List Approved, Health Product Declaration (HPD), Recycled Content
