Acoufelt design engineers stand ready to serve on your design team, marrying their deep understanding of the art and science of sound management to your vision with custom cutting, printing, shaping, and technical advice to soundscape your designs
Lead Time
3-6 Weeks
Manufacturing Location
United States
Technical Specifications
Product Features
Customizable
Size
Width: 48 in; Length: 40 in, 52 in, 64 in; Height ranges from end-to-end (2:1) Height A: 4 in up to 6 in H (1 in in crements), Height B: 8 in up to 12 in H (2 in in crements); Custom sizes available
Total Weight
12 mm, 0.49 lb./ft² (±10%)
Applications & Usage
Application Filter
Ceiling
Performance Metrics
Acoustics
NRC Rating - 0.85 - 200mm air gap; 0.80 - 400mm air gap; Test Method: ISO 11654-2002; Install Method: E200, E400; Rating Method: ASTM C423-09a; SAA Rating: 0.86 - 200mm air gap, 0.83 - 400mm air gap
Light Blocking
Complete
Sustainability
Human Health
Human Health Impact
Low Emitting/Low VOC, Formaldehyde Free, Health Product Declaration (HPD)
VOC Emissions Testing Methodology
CDPH / CHPS 01350 Compliant
Climate Health
Climate Impact
Environmental Product Declaration (EPD), ISO 14001 Environmental Management System (EMS), 100% Recyclable, Sustainability Action Plan
