For details, see USG Sustainability tool at usgdesignstudio.com or cgcdesignstudio.com; LR values are shown as averages; For details, see USG 30-Year Limited System Warranty Commercial Applications (SC2102); Maximum 2’x2’ with SQ edge panels; Coordinating USG Donn Brand grid color Reserve White, 4250, available for DXT™, DXF™, DXFF™, and DXI™ suspension system profiles; USG Juno™ Acoustical Panels with a “plant-based binder” label contain up to 65% plant-based material in the binder. For more information, please refer to the USG Juno™ Acoustical Panels Health Product Declaration, available at www.usg.com
Material & Finish
Content
Mineral Fiber
Availability & Procurement
Availability
Unavailable
Country Of Origin
United States
Manufacturing Location
Cloquet, MN
Technical Specifications
Size
2 ft x 2 ft x 1.3 in, 2 ft x 4 ft x 1.3 in, 30 in x 30 in x 1.3 in, 2 ft x 5 ft x 1.3 in, 2ft x 6 ft x 1.3 in
Total Weight
1.25 lb/sq.ft
Applications & Usage
Application Filter
Ceiling
Installation
Refer to Installation Guide PDF for details
Performance Metrics
Acoustics
NRC 0.95; CAC 30; ASTM E1264
Light Blocking
Complete
Maintenance
Can be cleaned easily with a soft brush or vacuum. To clean white panels, use a clean, white cloth with water or a mild detergent and wipe surface
Sustainability
Human Health
Human Health Impact
CDPH Standard Method v1.2-2017, Declare Product Label, Declare Product Label - LBC Red List Approved, Health Product Declaration (HPD), Low Emitting/Low VOC, UL GREENGUARD, UL GREENGUARD GOLD
VOC Emissions Testing Methodology
CDPH / CHPS 01350 Compliant
Climate Health
Climate Impact
Environmental Product Declaration (EPD), Sustainability Action Plan
GWP Functional Unit
kg CO2e/m2
Social Health & Equity
Sustainability Action Plan
Sustainability Action Plan
Circular Economy
Circular Economy
Declare Product Label, Declare Product Label - LBC Red List Approved, Environmental Product Declaration (EPD), Health Product Declaration (HPD), Manufacturer Take-Back Program, Recycled Content, Recycled Content - Pre-Consumer
