<ul><li>Available in three lengths with options for up to 9 seats</li></ul><ul><li>Options for integrated lighting</li></ul><ul><li>Available with two styles of backed and backless seating Kaleidoscope standard elements have been engineered to meet building codes across the U</li></ul><ul><li>S</li></ul><ul><li>Stringent load tests were performed by Landscape Forms</li></ul><ul><li>Based on this data, structural engineers calculated snow and wind load ratings for all standard elements</li></ul><ul><li>Kaleidoscope meets: Wind load of 146 mph, exposure C (IBC) Snow load of 40 lbs</li></ul><ul><li>per square foot @ 90 mph, exposure B Low voltage lighting (12 volts) is available</li></ul><ul><li>Lighting package consists of light housing and transformer and maybe ordered through Landscape Forms</li></ul><ul><li>Accepts low voltage MR16 lamp</li></ul><ul><li>Bulb and wiring are not included</li></ul><ul><li>Standard light housing is a bronze color</li></ul><ul><li>Additional colors available for an upcharge</li></ul><ul><li>Landscape Forms recommends a licensed contractor install lighting</li></ul><ul><li>Landscape Forms is not responsible for verifying that lighting meets local codes</li></ul>
Product Name
Kaleidoscope OS
Material & Finish
Content
Steel
Availability & Procurement
Availability
Confirm Stock Level with Sales Rep
Technical Specifications
Size
116 1/4 in W x 106 1/2 in H x 87 1/4 in D
Applications & Usage
Application Filter
Furniture
Installation
Kaleidoscope can be ordered for surface mounting at grade with cover plates or below grade mounting. Anchor bolts with nuts are used to level canopy posts for both mounting styles (not included). Ground and footing preparation is necessary. Kaleidoscope posts must be mounted on concrete footings. Caisson, spread, and pad style footings are all possible and custom designed for different building code conditions
