Decorative surface papers impregnated with melamine resins are pressed over Kraft paper core sheets impregnated with phenolic resin. Sheets are bonded together under high pressure and heat. Finished sheets are trimmed and back-sanded to facilitate bonding to substrate
Content
Phenolic resin-impregnated Kraft paper sheets and decorative surface papers impregnated in melamine resin
Finish
60 Matte
Format
Panel / Sheet
Availability & Procurement
Availability
Made to Order / Special Order
City Of Origin
Temple
Country Of Origin
United States
Custom Capabilities
Highly customizable. Special projects deserve special laminates. A range of specialty surface solutions are available. AEON™ Technology improves durability. Antimicrobial Protection helps guard against the growth of mold and mildew. High Wear increases abrasion resistance for high-traffic commercial projects. Traceless™ is anti-fingerprint. Chemsurf® provides exceptional chemical resistance. Fire-Rated Laminates meet or exceed well-known fire codes. Wilsonart X You enables personalization. Some colors and patterns can be made into writable surfaces
Lead Time
Ships out 21 days after order is placed
Technical Specifications
Dimensional Stability
ISO 4586 tested for Dimensional Stability. Product Type 362/367 Vertical Surface (VGP) = 0.5% in the machine direction and 0.8% in the cross direction. Product Type 372/377 Postforming (HGP) = 0.5% in the machine direction and 0.8% in the cross direction.
Edge End
Options include beveled, crescent, and mitered edges. Edgebands are also available for cabinets, doors, drawers, shelves, tables, and countertops. Refer to attached documents or contact your local rep for additional information
Impact Resistance
ISO 4586 tested for Impact Resistance. Product Type 362/367 Vertical Surface (VGP) = 40in. Product Type 372/377 Postforming (HGP) = 55in.
Overall Thickness
372
Product Features
Customizable
Size
48 in x 96 in, 60 in x 144 in
Total Weight
Product Type 362/367 Vertical Surface (VGP) = 0.186 lbs/sqft. Product Type 372/377 Postforming (HGP) = 0.26 lbs/sqft
Installation varies depending on application. Carbide-tipped saw and router blades should be used for cutting. Use the tool at high speed and feed slowly. To avoid cracking, radius all corners. Edges should be routered smooth. Refer to Spec Sheet attachment for additional information
Recommended Adhesive
Wilsonart® H20 Contact Adhesive works well in postforming applications. Use Wilsonart® 1730/1731 Contact Adhesive for non-postforming applications. Wilsonart® PVA Adhesive is ideal for bonding decorative laminate to wood substrates, in cold press, hot press, and postforming applications. For best results, apply adhesives at temperatures at or above 65 degrees F. Adhesives are UL GREENGUARD Gold Certified, quality for LEED points, and comply with SCAQMD and OTC regulations.
Suitable Substrates
Not structural — must be bonded to a suitable substrate such as particleboard, MDF, or plywood (with at least one A-face). Not recommended for direct application to plaster, concrete walls, or gypsum wallboard.
Performance Metrics
Abrasion Wear Resistance
ISO 4586 tested for Surface Wear Resistance. Meets or exceeds 400 cycles. Consider Wilsonart® High Wear for added abrasion resistance
Antimicrobial Note
Antimicrobial Protection (silver ion additive) is available as a factory order option on -38 and -60 finish laminates and comes standard on all HD® finishes. Requests for Wilsonart® VDL must be pre-approved by product management.
Flammability
Specific Flame Spread and Smoke Developed properties for the Virtual Design Library collection will depend on the specific design selected. Testing on individual designs will be required to verify these values
Light Blocking
Complete
Maintenance
To clean the surface, use a damp cloth or sponge and a mild soap or detergent. Rinse thoroughly with warm water and wipe dry. Avoid acidic or abrasive cleaners. A diluted bleach solution can be used as a disinfectant. Reference the Care & Maintenance Guide for additional information
Stain Resistance
ISO 4586 tested for Stain Resistance. No effect from Reagents 1-10. Slight effect from Reagents 11-15 for both product types
Water Resistance
ISO 4586 tested for Boiling Water Resistance. Slight effect on glossy surfaces. No effect on other finishes.
Sustainability
Human Health
Human Health Impact
CDPH Standard Method v1.2-2017, Declare Product Label, Declare Product Label - LBC Red List Approved, Health Product Declaration (HPD), Low Emitting/Low VOC, SCS Indoor Advantage Certified, SCS Indoor Advantage GOLD, UL GREENGUARD, UL GREENGUARD GOLD
VOC Emissions Testing Methodology
CDPH / CHPS 01350 Compliant
Climate Health
Climate Impact
ISO 14001 Environmental Management System (EMS)
Emissions
Low VOC emissions
Ecosystem Health
Ecosystem Health
Forest Stewardship Council (FSC) Certified|Forest Stewardship Council (FSC) Certified - Chain of Custody|ISO 14001 Environmental Management System (EMS)
Social Health & Equity
Social Equity Impact
Forest Stewardship Council (FSC) Certified, Forest Stewardship Council (FSC) Certified - Chain of Custody
Circular Economy
Circular Economy
Declare Product Label, Declare Product Label - LBC Red List Approved, Forest Stewardship Council (FSC) Certified, Health Product Declaration (HPD), Recycled Content, Recycled Content - Post-Consumer
