Limited 15 Year Commercial Warranty, Limited 15 Year Quantum Guard Elite® Wear Warranty
Material & Finish
Construction
Luxury Vinyl Tile with acoustic backing
Content
Non-Ortho Phthalate Vinyl
Finish
Quantum Guard Elite®
Format
Modular, Plank
Availability & Procurement
Availability
Unavailable
Country Of Origin
Republic of Korea
Lead Time
Please contact your sales rep for details
Order Increments
7 in x 48 in - 10 pcs, 23.3 ft2 (2.17 m2), 39.56 lbs (17.96)
Technical Specifications
Edge End
Unbeveled
Length
2
Overall Thickness
5
Size
7 in x 48 in (177.8 mm x 1219 mm)
Wear Layer Thickness
20 mil (0.5 mm)
Applications & Usage
Application Filter
Flooring
Installation
All arrows in the same direction. Planks should have end joints offset by at least 6 in and staggered to create a random appearance. Tiles should be installed block or staggered; when quarter turned, arrows should alternate
Performance Metrics
Acoustics
ASTM E492 - IIC 57 (6 in Concrete No Drop Ceiling); IIC 68 (6 in Concrete with Drop Ceiling)
Classification
ASTM F1700 Class III, Type B, Grade 2
Flammability
ASTM E648 Flooring Radiant Panel - Class 1, Greater than or equal to 0.45 watts/cm2; ASTM E662 Smoke Density - Less than or equal to 450
Light Blocking
Complete
Lightfastness
ASTM F1515 - Passes
Slip Resistance
Passes ASTM D2047 - 0.5
Sustainability
Human Health
Human Health Impact
CRI Green Label Plus Indoor Air Quality, CDPH Standard Method v1.2-2017, Low Emitting/Low VOC, SCS Global FloorScore Certified
May contribute to LEED credits, Building Product Disclosure & Optimization - EPDs, Building Product Disclosure & Optimization - Sourcing Raw Materials, Building Product, Disclosure & Optimization - Material Ingredients, IEQc2 - Low Emitting Materials
