Intended for commercial project specification only.
Series Name
Light Emitting
Warranty
1 Year
Material & Finish
Construction
An acrylic core is laminated between two panels, composed of either acrylic or polycarbonate
Content
Acrylic, Polycarbonate
Finish
Front cladding finshes include Matte, Frosted, Non-Glare, Opal, or Mist. Choose from Transparent, Mirror, or Opaque for the back cladding finish. Limitations may apply. Add White Protect to achieve colors not attainable with a transparent color alone
Format
Panel / Sheet
Availability & Procurement
Availability
Made to Order / Special Order
City Of Origin
Ypsilanti
Country Of Origin
United States
Custom Capabilities
Highly customizable. Can be colored, stamped, shaped, curved, mounted, or etched to specification. By request, create 3D shapes. Patterns are scalable. Add an interlayer or inlay to create custom looks with immense design opportunity
Lead Time
Ranges from 2-6 weeks for flat panels and 6-10 weeeks for complex solutions
State Of Origin
Michigan
Technical Specifications
Impact Resistance
ASTM D256 (notched) Tested 0.4 ft-lb/in (minimum)
Overall Thickness
1
Product Features
Customizable
Size
Highly customizable. Can be colored, stamped, shaped, curved, mounted, or etched to specification. By request, create 3D shapes. Patterns are scalable. Add an interlayer or inlay to create custom looks with immense design opportunity
Total Weight
Between 2 - 15lbs/sqft depending on thickness selection
Applications & Usage
Application Filter
Decor|Lighting|Partition|Wall
Installation
Installation method is governed by material thickness, opacity, size and weight. Attachment options include standoff points, construction adhesive, J or U-channels, clamps, edge grippers, cable suspension, invisible Z-clips, hinges, or slides and pivots.
Performance Metrics
Flammability
Acrylic clad option rated ASTM E84 Class C. Polycarbonate clad option rated ASTM E84 Class B. See EPD for additional information
Light Blocking
Complete
Lightfastness
UV-stable and non-yellowing
Maintenance
Wipe with warm soapy water and a small amount of mild dish soap or detergent or an anti-static plastic cleaner like Novus
Sustainability
Human Health
Human Health Impact
CDPH Standard Method v1.2-2017, Low Emitting/Low VOC
