5.329 SF per PC; 10.078 LB per PC; 1.891 LB per SF; 4 PC per BX; 21.316 SF per BX; 40.312 LB per BX; 27 BX per CRATE; 575.532 SF per CRATE
Technical Specifications
Overall Thickness
4
Size
20 in x 40 in
Tile Type
Field Tile
Tile Uniformity
Rectified
Applications & Usage
Application Filter
Bath|Countertop|Facade|Fireplace|Fireplace/Fireplace Surround|Flooring|Flooring/Wet Area Flooring|Kitchen|Wall|Wall/Wet Wall & Shower Wall
Installation
Dry Layout Required. Product MUST be installed in accordance with current TCNA Handbook Tile Methods. Dry laying of this product prior to installation is recommended. Per TCNA Guidelines, Running Bond/Brick Joint Patterns to be set with a Max. Offset of 33% and Min. Grout Joint of 1/8", unless otherwise Approved by Owner/Decision Maker. Porcelains that might hold dirt or debris must be cleaned with an appropriate pH neutral tile cleaner diluted with water. Scrub vigorously and rinse thoroughly. Consider this during the selection process. Use proper troweling techniques. Directional troweling and back-buttering Large Format Tiles helps ensure full coverage, mortar transfer, and bond. Grout release can be utilized prior to grouting. Clean with pH neutral tile cleaner
