Typically Stocked, Quick Ship, Stocked in North America
Country Of Origin
Germany
Lead Time
Varies, contact your sales rep for details
Manufacturing Location
Germany
Technical Specifications
Dimensional Stability
Meets Requirements
Overall Thickness
3
Size
Sheet - 49.21ft x 48in (15m x 1.22m), 39.37ft x 48in (15m x 1.22m); Plank - 24.015in x 8.07in (610mm x 205mm), 24.015in x 12in (610mm x 305mm), 48.03in x 15.94in (1220mm x 405mm)
Applications & Usage
Application Filter
Flooring
Installation
Glue down. Refer to Installation attachment for details
Performance Metrics
Acoustics
ASTM E2179 / ISO 140 Sound Absorption - ? Lw8dB (2mm), ? Lw10dB (3mm), compare only ? values
Compression
ASTM F970 Static Load Limirt - Residual compression of 0.002in with 800 lbs (= 0.005in with 250 lbs is required); Rolling Load Limit = 450 lbs/sq in, with no forklift traffic
Flammability
ASTM E648 (NFPA 253, NBSIR 75 950) - 0.98 Class 1 (2mm), 1.03 Class 1 (3mm), = 0.45 watts/sq. cm is required; ASTM E662 Smoke Density (NFPA 256, NBS) - 134 flaming and 109 non-flaming (2mm), 360 flaming and 203 non-flaming (3mm), <450 is required; CAN/ULC-S102.2 Surface Burning - FSC1 of 125 and SD of 370
Hardness
ASTM D2240 Shore type “A” - 92 achieved, = 85 is required
Light Blocking
Complete
Maintenance
No finishing, waxing, or sealing required. Refer to Maintenance attachment for details
Slip Resistance
ASTM D2047 Static coefficient of friction, Neolite dry 0.97 and Neolite wet 0.85 (2mm), Neolite dry 0.92 Neolite wet 0.91 (3mm), = 0.5 is required. Not recommended for ramps
Sustainability
Human Health
Human Health Impact
Blue Angel Certified
VOC Emissions Testing Methodology
CDPH / CHPS 01350 Compliant
Climate Health
Climate Impact
Blue Angel Certified, ISO 14001 Environmental Management System (EMS), UN Global Compact
GWP Functional Unit
kg CO2e/m2
Ecosystem Health
Ecosystem Health
Blue Angel Certified|ISO 14001 Environmental Management System (EMS)
