Karndean Commercial Opus 9 in Wide Plank | Product

Core Specs

General Information

Collection Name: Opus
Color Name: Niveus
Manufacturer SKU: WP411
Price Range: $$$
Product Name: Opus 9in Wide Plank
Warranty: Lifetime for Residential, 15 Year for Commercial

Material & Finish

Construction: Heterogeneous LVT
Content: Phthalate-Free Vinyl
Finish: K-Guard + PU Coating
Format: Modular, Plank

Availability & Procurement

Availability: Typically Stocked
Order Increments: 12 Planks/36 sq ft

Technical Specifications

Dimensional Stability: Passes ASTM F2199 at -0.004in/lin ft
Edge End: Micro Beveled Edge
Overall Thickness: 2.5
Size: 9in x 48in (228mm x 1219mm)
Wear Layer Thickness: 20 mil

Applications & Usage

Application Filter: Flooring
Installation: Glue Down. Refer to Installation attachment for details

Performance Metrics

Abrasion Wear Resistance: ASTM D3884 - 124,000 cycles
Acoustics: ASTM E2179-09 - Delta IIC = 4 dB; ASTM E492-09 - IIC = 44 dB (6in Slab w/ Drop Ceiling), IIC = 71 dB (6in Slab w/ Drop Ceiling + QuietChoice)
Classification: ASTM F1700 - Class lll Type B
Compression: ASTM F970 Static Load - 2,000 psi
Durability: Heavy Duty
Flammability: ASTM E648-06 - Class 1; Passes ASTM E662-06 Smoke Density <450; Passes FF 1-70, Federal Approval
Flexural Strength: Passes ASTM F137
Light Blocking: Complete
Lightfastness: Passes ASTM F1515 - Delta E = 5.0
Maintenance: Regular sweeping and mopping with a pH neutral cleaner. Refer to Maintenance attachment for details
Slip Resistance: DIN 51130 - R10; Passes ASTM D2047 - Dry 0.89

Sustainability

Human Health

Human Health Impact: Phthalates free, SCS Global FloorScore Certified, CDPH Standard Method v1.2-2017, Low Emitting/Low VOC, UL GREENGUARD
VOC Emissions Testing Methodology: CDPH / CHPS 01350 Compliant

Climate Health

Climate Impact: Global GreenTag Certified, ISO 14001 Environmental Management System (EMS), CARB Compliant, Environmental Product Declaration (EPD)

Ecosystem Health

Ecosystem Health: ISO 14001 Environmental Management System (EMS)

Social Health & Equity

Organizational Commitments: ISO 14001

Circular Economy

Circular Economy: Environmental Product Declaration (EPD)

Certifications & Disclosures

LEED: May contribute to LEED Credits
VOC Emissions Testing Certificate: UL Greenguard Certified or Gold, SCS Indoor Advantage
