<ul><li>Light Source - Integrated LED 3000K-1800K dim-2-warm (no bulb required)</li><li>Light Concept - The fixture emits a comfortable, diffused, glare-free light that is characteristic of Poul Henningsen's reflective three-shade-system. The fixture is available with white opal glass or soft-touch black-painted metal with a white interior. The translucent shades in triple-layered, hand-blown opal glass create a warm glow around the pendant, whereas the metal shades with their white-painted interiors reflect a fine and primarily downwardly directed light. An optional translucent white diffuser (included) is easy to insert for an even softer light distribution</li><li>Lighting Control - Phase dimming (mains dimm)</li><li></li><li>Efficacy - 56- 29 lm/W</li><li>Certifications - cULus</li><li>Dry Location</li><li>Protection class IP20</li><li>Controllability: Phase dimming or 0-10V dimming</li><li>LED Color Rendering: Ra=90 Dim-To-Warm LED CCT: 3000K (100%) to 1800K (5%) For the Esocket product variants</li><li>bulbs are not included</li><li>LED light source is part of the productColor Temperature - 3000KSDCM - 3</li><li>CRI - 90</li><li>Min. Dim Level (%) - 3,5</li><li>Inrush Current - 1,25A/250µs @120Vac / 1,8A/420 µs @ 277Vac</li><li>Power Factor - 1L80B50 (Hours) - >100.000</li></ul>
Product Name
PH 5/5 Pendant
Material & Finish
Content
Hand-blown white opal glass or spun aluminum, Bottom diffuser: Frosted glass, Suspension: Aluminum
Finish
White opal glass or soft touch black painted aluminum with white inner side shades, Matt black, powder coated
Lamping
LED Integrated
Availability & Procurement
Availability
Typically Stocked
Lead Time
3-6 Days
Technical Specifications
Lighting Features
Dimmable
Lighting Type
Pendant
Size
19.7 in W x 16.9 in H x 19.7 in L
Total Weight
9.0 lbs, 11.1 lbs
Applications & Usage
Application Filter
Ceiling|Lighting
Installation
Mounting-12 ft. 2-conductor; 18 AWG black cloth-covered power cord. Incandescent variants have a canopy of flat cone profile; 5.3" diameter x 1" tall. LED variants have a canopy of dome profile; 9.4" diameter x 4.3" tall. LED variants have an electronic; constant current; class II driver for 120-277V power supply housed inside canopy
