Recon Maple - Grooved Plank 8

Name: Recon Maple - Grooved Plank 8
Brand: MCM Acoustical
SKU: 101599287

Wood

Overnight

Commercial

Natural Maple

Sample size: 4.6 in x 7.9 in x 0.6 in

Arrives tomorrow

Color

(Natural Maple)

Edge End: Tongue & Groove
Overall Thickness: 19
Size: 8 ft and 10 ft (2.4 m & 3 m) lengths and are generally cut to size on site; The standard groove spacingsare 3/16 in (5 mm), 3/8 in (10 mm), and 5/8 in (15 mm). Panels are custom made to dimension required by the project with shop drawings provided by MCM Acoustical

Application Filter: Ceiling|Wall
Installation: MCM Acoustical's Direct Mounting system is designed to attach ceiling planks directly to ceiling grid / furring channels using MCMA plank clip; Planks weigh between 2 and 4 pounds per square foot, so use heavy-duty C-channels and furring channels; Secure the first plank / starter plank to ceiling substrate; Snap MCMA plank clip @ the grooved edge of the first plank; Screw MCMA plank clips directly to furring channels or other types of substrate like plywood strips; Install the next plank by inserting its tongue edge to the first installed plank groove; Repeat to snap MCMA plank clip @ the grooved edge of the second plank, and so on and so forth; Assembly drawing available in download section

Flammability: The Grooved Planks are Class A fire rated interior wood finish products as per ASTM E84 and CAN/ULC S102 tested in an accredited NVLAP test facility as a finished composite product using Class A components
Light Blocking: Complete
Maintenance: Clean the uncovered wooden surfaces of MCM Acoustical products following the cleaning guidelines provided by the manufacturer

Circular Economy: Forest Stewardship Council (FSC) Certified, Recycled Content, Recycled Content - Pre-Consumer

LEED: As all products are custom-fabricated, LEED credit opportunities are project by project. For detailed information, please contact MCM Acoustical
