Recon Walnut - Grooved Panel 8

Name: Recon Walnut - Grooved Panel 8
Brand: MCM Acoustical
SKU: 101599309

Wood

Overnight

Commercial

Natural Maple

Sample size: 4.5 in x 7.8 in x 0.6 in

Arrives tomorrow

Color

(Natural Maple)

Edge End: Edgebanded with matching veneer
Size: 5 ft x 10 ft (1.5 m, x 3 m); Three standard groove spacing options: 5/16 in (8 mm), 5/8 in (16 mm), and 1 1/4 in (32 mm)

Application Filter: Ceiling|Wall
Installation: CELING PANEL - DIRECT MOUNTING SYSTEM: MCM Acoustical's Direct Mounting system is designed to attach ceiling panels directly to ceiling grid using z-clips; Panels weigh between 2 and 5 pounds per square foot, so use heavy-duty C-channels and furring channels; Suspend the Grid with #12 Gauge hanger wire or equivalent; Hang wire directly from building structure with a maximum spacing of 4ft.; Attach plywood strips with z-clip track across furring channels as per assembly drawing, available on request; Assembly drawing available in download section; WALL PANEL - DIRECT MOUNTING SYSTEM: MCM Acoustical's Direct Mounting system is designed to attach wall panels directly to wall substrate using z-clips; Wall substrate can be 3/4 in thick x 3 in wide plywood strip or hat / furring channel screwed directly to wall frame; Aluminum z-clip tracks are screwed to wall substrate; Aluminum z-clips are attached to the back of the wall panels with wood screws provided. Typically mounting holes are factory located and pre-drilled. Spacing between clips must not exceed 24 in in both directions vertical and horizontal; Aluminum z-clip attached to the back of wall panel interlock with Aluminum z-clip track attached to wall substrate; Assembly drawing available in download section

Flammability: The Grooved Panels are Class A fire rated interior wood finish products as per ASTM E84 and CAN/ULC S102 tested in an accredited NVLAP test facility as a finished composite product using Class A components
Light Blocking: Complete
Maintenance: Clean the uncovered wooden surfaces of MCM Acoustical products following the cleaning guidelines provided by the manufacturer

Circular Economy: Forest Stewardship Council (FSC) Certified, Recycled Content, Recycled Content - Pre-Consumer

LEED: As all products are custom-fabricated, LEED credit opportunities are project by project. For detailed information, please contact MCM Acoustical
