Intended for commercial project specification only.
Series Name
Interactive
Warranty
1 Year
Material & Finish
Construction
An acrylic core is laminated between two panels, composed of either acrylic or polycarbonate
Content
Acrylic, Polycarbonate
Finish
Frosted
Format
Panel / Sheet
Availability & Procurement
Availability
Made to Order / Special Order
City Of Origin
Ypsilanti
Country Of Origin
United States
Custom Capabilities
Highly customizable. Can be cut-to-size, stamped, shaped, or etched to specification. By request, create 3D shapes. Can be layered with cladding, mirrors, and Zari films to create a number of unique visual properties
Lead Time
Ranges from 2-6 weeks for flat panels and 6-10 weeeks for complex solutions
State Of Origin
Michigan
Technical Specifications
Dimensional Stability
ASTM D696 Coefficient of linear thermal expansion 0.000034 in/in ? F
Edge End
Can be specified to suit the application
Impact Resistance
ASTM D256 (notched) Tested 0.4 ft-lb/in (minimum)
Overall Thickness
4
Product Features
Customizable
Size
Highly customizable. Can be cut-to-size, stamped, shaped, or etched to specification. By request, create 3D shapes. Can be layered with cladding, mirrors, and Zari films to create a number of unique visual properties
Total Weight
5 (3/4in thick) to 13.75 (2-1/4in thick) lbs/sqft
Applications & Usage
Application Filter
Countertop|Decor|Partition|Wall
Installation
Installation method is governed by material thickness, opacity, size and weight. Attachment options include standoff points, construction adhesive, J or U-channels, clamps, edge grippers, cable suspension, invisible Z-clips, hinges, or slides and pivots.
Performance Metrics
Flammability
Acrylic clad option rated ASTM E84 Class C. Polycarbonate clad option rated ASTM E84 Class B. See EPD for additional information
Light Blocking
Unknown
Lightfastness
UV-stable and non-yellowing
Maintenance
Wipe with warm soapy water and a small amount of mild dish soap or detergent or an anti-static plastic cleaner like Novus
Sustainability
Human Health
Human Health Impact
CDPH Standard Method v1.2-2017, Low Emitting/Low VOC
