Intended for commercial project specification only.
Material & Finish
Content
PET Felt
Availability & Procurement
Availability
Made to Order / Special Order, Quick Ship
City Of Origin
Elgin
Country Of Origin
United States
Custom Capabilities
Fixture sizing can be customized. Contact your sales representative for details
Lead Time
Standard - 8+ weeks, Quick Ship - 4+ weeks
Technical Specifications
Product Features
Customizable
Size
Size minimum 24 in L x 2.25 in W x 8.68 in H. Size maximum 114 in L x 2.25 in W x 8.68 in H
Applications & Usage
Application Filter
Ceiling|Lighting
Installation
3/64in aircraft cable, 7.5in of 1/4-20 threaded rod, & coupling nut supplied by TURF. UNISTRUT P1000T Standard, Universal steel Tee Grid, 1/16in Aircraft Cable with slotted cable drop supplied by installer. Refer to the PDF attached for details
Performance Metrics
Acoustics
ASTM C423-17; 0.75 NRC rating for material, 1.54 NRC for Slab Baffle Product
Light Blocking
Complete
Maintenance
Vacuum occasionally to remove any particulate matter and air-borne debris or dust. Compressed air can be used to dust the material in difficult-to-reach areas for large assemblies. Use standard household cleaners for spot cleaning
Sustainability
Human Health
Human Health Impact
CDPH Standard Method v1.2-2017, Declare Product Label, Declare Product Label - Declared, Declare Product Label - LBC Red List Free, Health Product Declaration (HPD), Intertek Clear Air - Gold, Low Emitting/Low VOC, REACH Compliant
VOC Emissions Testing Methodology
CDPH / CHPS 01350 Compliant
Climate Health
Climate Impact
CARB Compliant
Circular Economy
Circular Economy
Declare Product Label, Declare Product Label - Declared, Declare Product Label - LBC Red List Free, Health Product Declaration (HPD), Recycled Content, Recycled Content - Pre-Consumer
Certifications & Disclosures
Disclosure Level
100 ppm
Ingredient Disclosure
Health Product Declaration (HPD), Declare Product Label
