- Abrasion Wear Resistance
- ASTM D4060 - Greater than or equal to 20,000 cycles
- Acoustics
- ASTM E90 - STC 51, ASTM E492 - IIC 50, ASTM E2179 - IIC 21 (6in concrete slab). Refer to Technical Data attachment for details
- Classification
- ASTM F1700, Class lll, Type B
- Color Stability From Heat
- Surpasses ASTM F1514 - Average Delta E <8.0
- Compression
- Surpasses ASTM F1914 Residual Indentation - Average <8%, Maximum less than or equal 10%; Passes ASTM F970 Static Load - ±0.005in, 250 psi; SIM Test Static Load Limit - Greater than or equal to 1,000 lbs
- Electrical Resistance
- ANSI ESD STM97.2 Body Voltage - Average (Abs) Less than or equal to 2.0kV
- Flammability
- Passes ASTM E648 Radiant Panel - Class l, Greater than or equal to 0.45 w/cm2; ASTM E662 Smoke Density - Flaming & Non-Flaming, Less than or equal to 450; CAN/ULC S.101.2-10 - FSR less than or equal to 45, SDC less than or equal to 250
- Flexural Strength
- Surpasses ASTM F137 - No cracks/breaks (1in/25.4mm Mandrel)
- Light Blocking
- Complete
- Lightfastness
- Surpasses ASTM F1515 - Average Delta E <8.0
- Maintenance
- Refer to Maintenance attachment for details
- Slip Resistance
- Passes ASTM D2047 Coefficient of Friction - Greater than or equal to 0.6 Dry
