Swanbridge

Name: Swanbridge
Brand: Cambria
SKU: 100078748

Quartz Agglomerate Surfaces

Overnight

Commercial & Residential

$$$

Swanbridge

Sample size: 3 in x 3 in x 0.5 in

Arrives tomorrow

Finish

(Polished)

Collection Name: Marble Collection
Manufacturer SKU: 10009133
Price Range: $$$
Product Name: Swanbridge
Sample Note: All Cambria quartz surface products comply with the requirements in the Build America Buy America and Buy American Acts
Series Name: Signature Series
Warranty: A transferable Full Lifetime Warranty is available, which lasts the entire length of the product’s life, and is transferable to subsequent owners. Refer to Warranty PDF for more information
Manufacturer Notes: Variations in natural quartz stone color, pattern, size, shape, and shade are unique and inherent characteristics of this product. Material samples are small selections cut from a slab and do not fully show all design characteristics of a slab or the final installed product. Prior to purchase, view a larger representation of a design. Pot holders and trivets should be used to protect a quartz countertop from anything hot, as the material can be damaged by sudden changes in temperature

Construction: Pure quartz, pigments, and binders are agglomerated, heated, and cast into through-body color slabs
Content: Quartz, binder, and pigment
Finish: Polished and Cambria Matte
Format: Slab
Surface Sheen: Glossy, Matte

Dimensional Stability: Coefficient of Thermal Expansion (ASTM C-531) Tested. Result of 1.2x10^-5 in/degrees F.
Impact Resistance: ASTM C-648 Tested. Result of 3,661 lbf
Length: 132
Overall Thickness: 3
Size: 132 in x 65.5 in (Jumbo). Check with your local rep/ installer/fabricator for slab size availability per design, includ ing the largest size able to be fabricated versus slab size listed
Total Weight: 5lbs/ft2 (24 kg/m2) for 1 cm, 10 lbs/ft2 (48 kg/m2) for 2 cm, and 15 lbs/ft2 (72 kg/m2) for 3 cm

Application Filter: Bath|Countertop|Fireplace|Flooring|Kitchen|Furniture|Stair & Elevator|Wall|Wall/Backsplash|Wall/Wet Wall & Shower Wall
Installation: Install in accordance with brand’s instructions on approved shop drawings; to be done by an approved installer, certified in writing. Cut and polish with water-cooled powered tools. Any cutouts shall have a minimum of 0.25in radius. For horizontal surfaces, apply a continuous bead of adhesive at the intersection point of the countertop and the substrate or cabinet. This bead will be continuous throughout the entire perimeter. Allow gaps for expansion of no less than 0.125in per 10ft when installed between walls or other fixed structures. Can be thermoformed to a 120 in minimum inside radius. Restrictions and limitations vary for designs and thicknesses
Recommended Adhesive: Structural grade 50-year 100% silicone or epoxy adhesive for mounting. Adhesive that will be visible in finished work shall be tinted to match quartz surface. Cambria’s adhesives for setting seams in countertops are GREENGUARD approved.
Suitable Substrates: Not a structural support material and must be supported in every application

Abrasion Wear Resistance: ASTM C-1353 Tested. Result of 223
Bond Strength: ASTM C-482 Tested. Result of 205 psi.
Compression: ASTM C-170 Tested. Result of 24,750 psi.
Flammability: ASTM E-84 Surface Burning Characteristics 17 (Class ARating); ASTM E-662 Smoke Density Flaming-196 / Non-flaming-69
Flexural Strength: Modulus of Rupture (ASTM C-99) Tested. Result of 6,800 psi.
Maintenance: Simply wash with a soft cloth and warm water; use mild soap if desired. Do not apply any sealers, penetrants, or topical treatments
Tensile Strength: ASTM C-648 3,661 ibf; ASTM C-99 Modulus of Rupture 6,800 psi
Water Absorption: Nonporous
Weather Resistance: Thermal Shock (ASTM C-484) Tested. Passes 10 cycles. Resistance to Freeze Thaw Cycling (ASTM C-1026) Tested. Unaffected after 300 cycles

Human Health Impact: Declare Product Label - LBC Red List Approved, NSF/ANSI 51 Certified Food Equipment Materials, Low Emitting/Low VOC, CDPH Standard Method v1.2-2017, Declare Product Label - Declared, Health Product Declaration (HPD), UL GREENGUARD, UL GREENGUARD GOLD

Circular Economy: Health Product Declaration (HPD), Declare Product Label - Declared, Declare Product Label - LBC Red List Approved
