Acoufelt Swell Fracture Tile Wall Panel | Product

Core Specs

General Information

Collection Name: Premier Collection
Manufacturer SKU: WSFSW
Product Details: <ul><li>Made from FilaSorb™</li><li>Breathable</li><li>High resistance to fire</li><li>Thermal efficiency</li><li>Smooth surface finish</li></ul>
Product Name: Swell Fracture Tile Wall Panel
Warranty: 20 years after installation date, 20 Year Lightfastness Warranty

Material & Finish

Construction: Non-woven polyester fiber thermo bonded compressed felt
Content: FilaSorb™ (100% Polyester)
Format: Panel / Sheet

Availability & Procurement

Availability: Made to Order / Special Order
Country Of Origin: United States
Custom Capabilities: Acoufelt design engineers stand ready to serve on your design team, marrying their deep understanding of the art and science of sound management to your vision with custom cutting, printing, shaping, and technical advice to soundscape your designs
Lead Time: 3-6 Weeks
Manufacturing Location: United States

Technical Specifications

Product Features: Customizable
Size: 12 in W x 12 in H (305 mm W x 305 mm H)
Total Weight: 12mm - 0.49 lb./ft² (±10%); 24mm - 0.98 lb./ft² (±10%)

Applications & Usage

Application Filter: Wall

Performance Metrics

Acoustics: NRC Rating 12mm - 0.45; NRC Rating 24mm - 0.60
Light Blocking: Complete

Sustainability

Human Health

Human Health Impact: Declare Product Label - LBC Red List Free, Formaldehyde Free, Health Product Declaration (HPD), Declare Product Label - LBC Red List Approved, CDPH Standard Method v1.2-2017, Low Emitting/Low VOC, SCS Indoor Advantage GOLD
VOC Emissions Testing Methodology: CDPH / CHPS 01350 Compliant

Climate Health

Climate Impact: Environmental Product Declaration (EPD), 100% Recyclable, ISO 14001 Environmental Management System (EMS), Sustainability Action Plan

Ecosystem Health

Ecosystem Health: ISO 14001 Environmental Management System (EMS)

Circular Economy

Circular Economy: Recycled Content - Post-Consumer, 100% Recyclable, Declare Product Label - LBC Red List Free, Declare Product Label - LBC Red List Approved, Recycled Content, Environmental Product Declaration (EPD), Health Product Declaration (HPD)

Certifications & Disclosures

Disclosure Level: 100 ppm
Environmental Product Declaration: Product-Specific EPD
Ingredient Disclosure: Declare Product Label
