Drain assembly not included. Color shown on screen may vary from actual product. Request sample prior to product selection
Material & Finish
Construction
Non-Porous
Content
Resin
Availability & Procurement
Availability
Typically Stocked
Country Of Origin
China
Technical Specifications
Dimensional Stability
ASTM D696 Thermal Expansion Tested. 3.49 x 10 -5 in/in/ C (2.08 x 10 -5 in/in/°F)
Impact Resistance
ASTM D256-10 C IZOD Notched Impact Strength Tested. 2 J/m; ASTM D5420-10 Impact Strength Tested. Mean Failure Height 803mm, Mean Failure Energy 28J
Length
785
Product Features
ADA Compliant
Size
18.875in W x 9.813in H x 30. 875in L
Applications & Usage
Application Filter
Bath
Installation
Can be machined with woodworking tools and is thermoformable. If installing horizontally, support with MDF, wood, or metal. Do not use full underlayment. Leave gaps to allow for expansion and contraction. Refer to Fabrication Guide for more information
Performance Metrics
ADA
ADA Compliant when installed in accordance to ADA guidelines
Cleaning with soapy water or ammonia-based cleansers will remove most dirt and stains. Stubborn stains can be removed with a multi-surface cleaner, bleach, bleach-based cleansers or nonabrasive cleansers. Refer to Care and Maintenance document for more information
